Your TP-112HD XGA/HD Line Transmitter – DA

3.3 About the TP-112HD

Your Kramer TOOLS TP-112HD XGA/HD Line Transmitter - DA:

• Receives a computer graphics

/HD

signal and transmits it over two

CAT 5 cables to appropriate receivers

• Has a transmission range of more than 300 ft. (more than 100 meters)

• Includes the Power Connect feature

• Is 12V DC fed

3.4 Recommendations for Achieving the Best Performance

To ac

hieve the best performance:

• Use only good quality connection cables

to avoid interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables).

• Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer product

away from moisture, excessive sunlight and dust

4 Your TP-112HD XGA/HD Line Transmitter – DA

Figure 1, Figure 2, Figure 3 and Table 1 define the TP-112HD:

1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on a 15-pin HD connector

having a resolution from VGA up to UXGA

2 The TP-112HD accepts high definition resolutions: 480p, 576p, 720p, 1080i, and 1080p

3 Note that the CAT 5 connectors exclude audio

4 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
