613T, 613R - Using the 3G-SDI Mini Optical Set

4 Using the 3G-SDI Mini Optical Set

This section describes how to:

 Connect the detachable optical 3G-SDI Mini Optical Transmitter/ Receiver

(see Section 4.1)

 Avoid pitfalls when using the 613T and 613R (see Section 4.2)

4.1 Connecting the 3G-SDI Mini Optical

Transmitter/Receiver Set

To connect the 613T 3G-SDI Mini Optical Transmitter with the 613R 3G-SDI Mini

Optical Receiver, as the example in Figure 1 illustrates, do the following:

1. Connect the BNC connector of the SDI Source (for example, a camera)

directly to the 613T BNC connector.

Avoid using any intermediate cable which may result in signal quality deterioration.

2. Plug the 5V power adapters to the transmitter and to the receiver, and

connect the adapters to the mains electricity.

The blue LED lights.

3. Connect the 613R BNC connector directly to the BNC connector of the display

device.

4. Remove the protective cover from the optic fiber ST connector on the 613T

and connect to the fiber optic cable.

Use glass single-mode fiber optic cable with 1310, 1550nm bandwidth on ST

connectors.

5. Remove the protective cover from the optic fiber ST connector on the 613R

and connect to the other side of the fiber optic cable.

6. Turn ON the power on the source and the display devices.
