VA-10 - Connecting the VA-10 5

4 Connecting the VA-10

Always switch off the power to each device before connecting it to your

VA-10. After connecting your VA-10, connect its power and then

switch on the power to each device.

To connect the VA-10 (as the example in Figure 2

illustrates), do the following:

1. Connect a computer graphics source to the XGA INPUT of a PT-110 XGA

Line Transmitter and connect the LINE OUTPUT on the PT-110 to the LINE

IN RJ-45 connector on a TP-120

XGA Line Receiver unit. Connect the XGA

OUT connector on the TP-120 unit to the 15-pin HD (F) INPUT connector on

the VA-10.

Refer to the PT-110, WP-110, TP-120 user manuals that can be downloaded at

http://www.kramerelectronics.com

2. Connect the 15-pin HD (F) OUTPUT connector on the VA-10, to the RGB

acceptor (for example, a projector).

3. On each of the VA-10, TP-120 and PT-110, connect the 12V DC power adapter

to the power socket and connect the adapter to the mains electricity.

4. Use the BLUE, RED and GREEN trimmers to adjust the blue, red and green

color delays, as required.
