Kramer T10F [2/2] Installation instructions

Connecting the Cables

When replacing blank inserts with connector inserts (for example, VGA, audio, HDMI and so on):

1. Insert the cables to their appropriate connectors from underneath.

2. Secure the cables to the tie holes on the TBUS-10XL.

Do not secure the cables too tightly or too loosely. Leave a small amount of slack.

After the TBUS-10XL is connected to mains power and the proper cables, it is ready for use.

Adjusting the Height of the Inner Frame

If needed, you can adjust the inner frame to one of the several possible heights to accommodate

large or bulky cables. To adjust, perform the following:

1. Remove the height adjustment screws, while supporting the frame from underneath with

your fingers.

2. Raise or lower the connecting surface to the required height, insert the screws, and tighten

them in place.

KRAMER ELECTRONICS LTD.

Installation

Instructions

MODEL:

T10F-22M

Inner Frame

For the latest information on our products and a list of Kramer

distributors, visit our Web site where updates to this user manual may be

found.

We welcome your questions, comments, and feedback.

Web site:

www.kramerelectronics.com

E-mail: info@kramerel.com

P/N: 2900-300225 Rev 1

P/N:

2900- 300225

Rev:

SAFETY WARNING

Disconnect the unit from the power

supply before opening and servicing
