4 Connecting the WP-120

Always switch off the power to each device before connecting it to your

WP-120. After connecting your WP-120, connect its power and then

switch on the power to each device.

To connect the WP-120:

1. Connect the line out RJ-45 connector of the transmitter to the pre-installed

UTP wiring in the wall box opening that connects via UTP cabling to the

LINE IN RJ-45 connector of the WP-120.

2. Connect your 12V DC power supply to the POWER SUPPLY pins, taking

care that polarity is correct.

Connect the wire labeled “+” to the +12V pin, and the wire labeled “–” to the GND pin.

3. Insert the WP-120 directly into the wall box opening, and then mount the

front panel securely using the screws.

4. Connect the XGA acceptor to the XGA OUT 15-pin HD connector.
