Kramer WP-120 [12/14] Technical specifications

WP-120 - Technical Specifications

5 Technical Specifications

INPUT:

1 RJ-45 connector

OUTPUT:

1 XGA on an 15-pin HD connector

MAX. OUTPUT LEVEL:

1.5Vpp

RESOLUTION:

Up to UXGA

DIFF. GAIN:

2.7% (for the transmitter/receiver pair)

DIFF. PHASE

0.22Deg

K-FACTOR:

<0.1%

S/N RATIO:

61dB

CONTROLS:

Level: -9.4dB to +2.2dB; EQ.: 0dB to +30.9dB

COUPLING:

POWER CONSUMPTION:

12V DC, 250mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

USA: 6.9cm x 3.8cm x 11.4cm (2.72" x 1.5" x 4.5", W, D, H)

Belgium and Germany: 8cm x 3.8cm x 8cm

(3.15" x 1.5" x 3.15", W, D, H)

UK and most of Europe: 8.6cm x 3.8cm x 8.6cm

(3.39" x 1.5" x 3.39", W, D, H)

WEIGHT:

0.14kg (0.31lbs) approx.

ACCESSORIES:

Power supply

OPTION:

RK−121WP 19" rack adapter

Specifications are subject to change without notice at http://www.kramerelectronics.com
