Technical Specifications

6 Technical Specifications

Table 2 lists the technical specifications:

Table 2: Technical Specifications

INPUTS:

of the F-021 XGA / Audio Line Amplifier Mounting Box

1 UXGA on a 15-pin HD (F) connector

1 Unbalanced stereo audio on a 3.5mm mini connector

1 Power 12V DC on a 2-pin terminal block connector

OUTPUTS: 1 RGBHV for XGA on an 8-pin terminal block connector

SCL and SDA for EDID on a 2-pin terminal block connector

1 Balanced stereo audio on a 5-pin terminal block connector

MAX. OUTPUT LEVEL: Video: 1.7Vpp Audio: ±8.4Vpp

RESOLUTION: Up to UXGA

AUDIO BANDWIDTH: Video: 400MHz Audio >30kHz

DIFF. GAIN: 0.1%

DIFF. PHASE: 0.1 Deg

K-FACTOR: <0.05%

S/N RATIO: Video: 69dB @5MHz Audio: 88dB

CROSSTALK: Audio: 64.5dB from video

CONTROLS: XGA EQ.: 0dB to 8dB; audio level: -74dB to 12dB; power LED

COUPLING: Video: DC Audio: IN = AC, OUT = DC

AUDIO THD + NOISE: 0.004%

AUDIO 2

HARMONIC: 0.0002%

POWER SOURCE: 12V DC 70mA

DIMENSIONS: Closed: 7.5cm x 15.7cm x 4.4cm (2.95” x 6.18" x 1.73") W, D, H

Open: 7.5cm x 20.7cm x 4.4cm (2.95” x 8.15" x 1.73") W, D, H

WEIGHT: 0.19kg (0.42lbs) approx.

ACCESSORIES: Power supply

1 Specifications are subject to change without notice
