Connecting a PS-1DVI DVI Power Supply
3
3
Lower Side Panel
Top Side Panel
Lower Side Panel
Top Side Panel
Figure 1: PS-1DVI DVI Power Supply
Table 1: PS-1DVI DVI Power Supply Features
#
Feature
Function
1 DVI IN Connector Connect to the DVI source
2 5V DC +5V DC connector for powering the unit
3 DVI OUT Connector Connect to the DVI acceptor
4 POWER LED Illuminates when receiving power
4 Connecting a PS-1DVI DVI Power Supply
To connect the PS-1DVI, do the following:
1. Connect the DVI graphics source (for example, a laptop) to the DVI IN
connector on the PS-1DVI.
2. Connect the DVI OUT connector to the DVI acceptor (for example, a plasma
display).
3. Connect the 5V DC power adapter to the power socket on the PS-1DVI and
connect the adapter to the mains electricity.
