Yarden 8-C - Your Yarden 8-C Closed-back Ceiling Speakers

Each Closed-back Ceiling speaker is supported by a C-ring and two tile rails. The tile

rails prevent the speakers from falling if the tile itself comes out or falls apart, as

their ends catch onto the T-grid. When mounting onto the ceiling tiles, use both

supports. When mounting onto a sheetrock ceiling, the C-ring alone is used to

reinforce the ceiling material.

Be sure that the tiles can support the speaker. Smaller sized tiles or

fiberglass-type tiles cannot support the weight of the speakers.

When this is the case, the speakers will need additional support.

Figure 3 shows a schematic diagram of the Yarden 8-C:

Figure 3: Yarden 8-C Schematic Diagram
