10
Galil 6-I - Technical Specifications
6 Technical Specifications
Galil 6-I
Audio and Power
DESCRIPTION:
2−Wayin-wall speakers
FREQUENCY RESPONSE:
50Hz to 20kHz @ -15dB
60Hz to 20kHz @ ±3dB
WOOFER:
6.5”(165mm) polypropylene with rubber surround
TWEETER:
1”(25.4mm) silk
IMPEDANCE:
8Ω
SENSITIVITY:
87dB SPL, 1W@1m
MAX SPL:
Continuous: 109dB
Peak: 112dB
POWER HANDLING:
80W RMS
220W continuous program
CROSSOVER FREQUENCY:
1.8kHz
COVERAGE ANGLE:
107 (if mounted on the ceiling)
DIRECTIVITY FACTOR (Q):
3.4, averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI):
5.3dB averaged 1kHz to 10kHz
INPUT CONNECTOR:
Terminal block
Shipping and Installation
MATERIALS:
ABS Frame, aluminum grille, safety cord attached
to the grille
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
WEIGHT PER SINGLE SPEAKER:
1.7kg (3.75lbs) approx.
SHIPPING WEIGHT (FOR PAIR):
2.6kg (11.5lbs) approx.
DIMENSIONS:
22.8cm x 8cm x 30.4cm (8.98”x3.15”x11.97”)W,
D, H
Cutout dimensions: 18.5cm x 27.3cm (7.28” x
10.75”), W, H
INSTALLATION CLEARANCE:
Mounting depth: 7cm (2.76”)
INCLUDED ACCESSORIES:
Cutout template
COLORS:
Available in white
Specifications are within a 10% tolerance and are subject to change without notice at
http://www.kramerelectronics.com
