ALTERNATIVE PARTS
--- 2 ---
ITEM
NO.
CODE NO.
DESCRIPTION
REMARKS
NO.
USED
PARTS
4 -- 04
DS 12DVB2
1311-959 SPECIAL SCREW (LEFT HAND) M6X23 1
2 320-684
DRILL CHUCK 13VLRG-N (W/O CHUCK WRENCH)
1
3 320-926 GEAR BOX ASS’Y 1 INCLUD. 4-27
4 319-755 CAP 1
5 319-754 CLICK SPRING 1
6 319-743 NUT 1
7 319-742 SPRING 1
8 319-741 THRUST WASHER 1
9 320-927 FRONT CASE 1
10 319-744 ROLLER 6
11 306-936 STEEL BALL D5 6
12 320-928 LOCK RING 1
13 319-745 RING GEAR 1
14 320-929 CARRIER 1
15 319-769 PLANET GEAR (C) SET (3 PCS.) 3
16 312-704 WASHER (A) 1
17 319-748 REAR CASE 1
18 312-712 SCREW SET D3X12 (4 PCS.) 4
19 319-753 SHIFT ARM 1
20 319-750 SLIDE RING GEAR 1
21 319-749 PINION (C) 1
22 319-768 PLANET GEAR (B) SET (3 PCS.) 3
23 319-751 PINION (B) 1
24 319-767 PLANET GEAR (A) SET (3 PCS.) 3
25 319-752 FIRST RING GEAR 1
26 312-716 WASHER (B) 1
27 316-955 MOTOR SPACER 1
28 320-931 MOTOR 1
29 313-687
TAPPING SCREW (W/FLANGE) D3X16 (BLACK) 7
30 NAME PLATE 1
*31 958-523 MACHINE SCREW (W/SP. WASHER) M4X8 2
*31 317-333 MACHINE SCREW (W/SP. WASHER) M4X6 2 FOR USA, CAN, AUS, NZL
32 320-930 HOUSING (A).(B) SET 1
*33 320-159 INTERNAL WIRE (BLACK) 160L 1
*33 319-759 INTERNAL WIRE (BLACK) 100L 1 FOR USA, CAN, AUS, NZL
34 319-758 INTERNAL WIRE (RED) 130L 1
35 318-245 DC-SPEED CONTROL SWITCH 1
36 319-760 PUSHING BUTTON 1
*37 318-247 FERRITE CORE 1 EXCEPT FOR USA, CAN, AUS, NZL
38 318-234 SHIFT KNOB 1
39 HITACHI LABEL 1
40 315-141 TERMINAL SUPPORT (A) 1
41 306-952 STRAP (BLACK) 1
*42 320-387 BATTERY EB 1220BL (W/ENGLISH N.P.) 2
*42 320-386 BATTERY EB 1220BL (W/ENGLISH N.P.) 2 FOR USA, CAN
*42 320-685 BATTERY EB 1220BL (W/ENGLISH N.P.) 2 FOR NZL
*42 320-686 BATTERY EB 1222HL (W/ENGLISH N.P.) 2 FOR BEL
