PERIODIC SERVICE
MAINTENANCE TIME TABLE
Initial maintenace General maintenance
period
Items
Contents
10 hours
(month）
50 hours
(3 months)
100 hours
(6 months)
200 hours
(1 year)
Anode
Inspection/ replacement
○ ○
Spark plug
Cleaning/ adjustment
/ replacement
○ ○
Grease points
Greasing
○
Bolts and nuts
Inspection
○ ○
Fuel filter
Inspection/ replacement
○ ○ ○
Fuel tank Inspection/ cleaning ○
Throttle cable
Inspection/ adjustment/
replacement
○ ○
Idling speed
Inspection/ adjustment
○ ○
Start-in-gear
projection
Inspection/ adjustment
○ ○
Engine oil
Replacement
○ ○
Oil filter
Replacement
○
Valve clearance
(OHC）
Inspection/ adjustment
○ ○
Ignition timing
Inspection
○ ○
Thermostat
Inspection
○
Cooling water
passage
Inspection/ Cleaning
○ ○
Gear oil
Replacement
○ ○
Water pump
Inspection
○
Propeller
Inspection/ replacement
○ ○
Timing belt
Inspection/ replacement
○ ○
CAUTION:
After running the outboard engine in salt water, waste water or mud water, wash over
the engine by fresh water immediately.
If using leaded gasoline frequently, check the valve and components each 100 hours.
Timing belt should be changed every 1000 hours (5 years).
14
