![Parsun F20A FWS [89/106] Disassembling and inspection 1 remove limitative rod and bolt m6x145 2 remove nut and bolt of tilt stopper plate and remove the tilt stopper plate](/img/pdf.png)
Parsun F20A FWS [89/106] Disassembling and inspection 1 remove limitative rod and bolt m6x145 2 remove nut and bolt of tilt stopper plate and remove the tilt stopper plate
![Parsun F20A FWS [89/106] Disassembling and inspection 1 remove limitative rod and bolt m6x145 2 remove nut and bolt of tilt stopper plate and remove the tilt stopper plate](/views2/1156082/page89/bg59.png)
G
G
G
2 Nm
22 Nm
8 Nm
REMARKS
PART NO.
DESCRIPTION
右夹紧托架组件
F15-01010200
45
1
1
1
2
1
1
1
2
2
2
1
1
1
1
1
1
F15-01010314
F15-01010315
F4-01010005
F15-01010313
F15-01010312
F15-01010305
F4-01010004
F15-01010102
角度锁紧内架
角度锁紧架拉簧
角度锁紧架扭簧
角度锁紧外架
角度锁紧短轴
角度支撑组件
角度锁紧手柄组件
艉板夹紧手柄
艉板夹紧螺杆
艉板夹紧手柄铆钉
角度支撑定位轴
小垫圈6
六角螺母M6
艉板夹紧圆盘
锁紧支架连杆
F4-01010003
GB/T6170-M6
GB/T848-6
F15-01010317-1
F15-01010317-2
F15-01010317-3
F15-01010307
44
43
42
41
40
39
38
33
37
36
35
34
32
31
30
Disassembling and inspection
1. Remove limitative rod and bolt (M6X145).
2. Remove nut and bolt of tilt stopper plate, and remove the tilt stopper plate.
