Yanmar 6LPA-STP2 [2/2] Model zt370 steerable z drive with dual prop type hydraulic actuated multi friction disc clutch dry weight 100 kg reduction ratio 1 65 1 65 1 78 1 78 propellor speed 2424 2424 2...
