ICF-P26_RU2 [GB/RU/KZ]

4-573-992-41(1)

English

WARNING

Do not install the appliance in a confined space,

such as a bookcase or built-in cabinet.

Do not expose the appliance to naked flame

sources (for example, lighted candles).

Batteries or batteries installed apparatus shall

not be exposed to excessive heat such as

sunshine, fire or the like.

The nameplate and important information

concerning safety are located on the bottom

exterior.

FM/AM Radio

Manufacturer: Sony Corporation, 1-7-1, Konan,

Minato-ku, Tokyo 108-0075, Japan

Made in China

Importer on the territory of the CU:

CJSC “Sony Electronics”, 123103, Moscow,

Karamyshevsky lane 6, Russia.

Organization accepting on the territory of

Kazakhstan the claims from the users:

CJSC “Sony Electronics”

Representative office in Kazakhstan

Dostyk avenue, bld. 117/7, 050010, Almaty,

Kazakhstan

Production Date

The date of manufacture is specified on the

barcode label on the carton and the product in

the following format: MM-YYYY, where

MM-month and YYYY-the year of

manufacturing.

This product is designed for listening to FM

and AM radio stations.

Precautions

• Operate the unit only on 3 V DC with two R6/

LR6 (size AA) batteries.

• Avoid exposure to temperature extremes,

direct sunlight, moisture, sand, dust or

mechanical shock. Never leave in a car parked

under the sun.

• Should anything fall into the unit, remove the

batteries, and have the unit checked by

qualified personnel before operating it any

further.

• Since a strong magnet is used for the

speaker, keep personal credit cards using

magnetic coding or spring-wound watches

away from the unit to prevent possible

damage from the magnet.

• When the casing becomes soiled, clean it

with a soft dry cloth moistened with mild

detergent solution.

• Never use abrasive cleansers or chemical

solvents, as they may deform the casing.

• Make sure not to splash water on the unit.

This unit is not waterproof.

• Listening with this unit at high volume may

affect your hearing. For traffic safety, do not

use this unit while driving or cycling.

• Under certain circumstances, especially when

the air is very dry, it is not uncommon to

experience a discharge of static electricity, or

shock, when your body comes in contact with

another object, in this case the ear buds

touching your ear(s). The energy from this

natural discharge is extremely small and is

not emitted by your product but rather a

natural environmental occurrence.

• Depending on the strength of radio signals,

the TUNE (tuning) indicator may not light up

even if a broadcast is being received.

Furthermore, the indicator may light up

incorrectly due to extraneous noise even

when a broadcast is not being received. Use

the TUNE indicator as a reference.

• When connecting headphones (not supplied)

to the unit, use headphones with a stereo

(3-pole) or monaural (2-pole) mini plug.

Sound may not be heard when using other

types of plugs.

* When connecting stereo

headphones, you will hear monaural

sound in both ears.

1 ring

2 rings

Other types

of plugs

cannot be

used.

Compatible

plug types

3 or more rings

Monaural

mini plug

Stereo

mini plug*

When to replace the batteries

Replace all batteries with new ones when the

BATT (battery) indicator becomes dim or the

sound becomes weak.

Notes on batteries

• Do not mix an old battery with a new one or

mix different type of batteries.

• When you are not going to use the unit for

a long time, remove the batteries to avoid

damage from battery leakage and

corrosion.

• Check if the batteries are inserted in the

correct orientation ( and ) when the

radio does not turn on after battery

replacement.

• Batteries have a recommended use-by date

for proper use. When using expired

batteries, battery life will be extremely

short. Check the use-by date on the

batteries and if they are expired, replace

them with new ones.

If the battery compartment cover comes

off

Insert the right hook tab

of the lid into the right

hole, then put the left

hook tab on the edge of

the opening and slide it

slowly until it fits into the

left hole.

If you have any questions or problems

concerning your unit, please consult your

nearest Sony dealer.

Specifications

Frequency range:

FM: 87.5MHz – 108MHz/AM: 530kHz –

1,605kHz

Speaker:

Approx. 5.7cm dia., 8Ω

Output:

 (headphones) jack (ø3.5mm mini jack)

Power output:

100 mW (at 10% harmonic distortion)

Power requirements:

3 V DC, two R6/LR6 (size AA) batteries

Battery life*:

Approx. 100 hours (FM reception)/Approx. 110

hours (AM reception)

* When listening through the speaker on alkaline

batteries manufactured by Sony (LR6SG). The actual

battery life varies significantly depending on battery

type (such as rechargeable batteries), usage and

circumstances.

Dimensions (W/H/D):

Approx. 69.5 mm × 119 mm × 38 mm (incl.

projecting parts)

Mass:

Approx. 190 g (incl. batteries)

Quantity:

Unit (1), Hand strap (1)

Supplied accessory*:

Hand strap (1)

 Attachment loop: Polyester

 Connector: Olefin-based thermoplastic elastomer

 Strap: Polyamide

 Dimensions : Approx. 230 mm × 5.5 mm

 Country of origin: Made in China

* Headphones are not included.

Design and specifications are subject to

change without notice.

R6/LR6 (AA)

For Better Reception/Для улучшения приема/

Сигналды жақсы қабылдау үшін

4-573-992-41(1)

Operating Instructions

Инструкция по эксплуатации

Басқару нұсқаулары

FM/AM Radio

ICF-P26
