Miscellaneous

Precautions

Note

The surface of the rubber roller is soft and easily

scratched. When cleaning it, be carefull not to scratch

and not to pull the surface of the rubber roller.

To clean the cleaning roller used for removing

dust accumulated on the paper:

Open the maintenance door, and then clean the roller

with a soft cloth or the like moistened with alcohol.

Note

The surface of the rubber roller is soft and easily

scratched. When cleaning it, be carefull not to scratch

and not to pull the surface of the rubber roller.

When the following symptoms appears

When the message “HEAD IN COOLING”

begins to appear on the information display

frequently:

Ventilation holes are provided on the front and rear of

the printer. Clean the filter placed on the front panel of

the printer. If the filter is dirty, the time required for

cooling the thermal head is lengthened and this causes

the printing time to become longer.

Remove the fan cover, and then the filter.

Wash the filter with water to remove the dust.

Note

Do not rub the netting of the filter roughly.

After the filter has been dried completely, reset the

filter and fan cover on the front panel as they were.

Note

Be sure to attach the filter onto the fan cover correctly. If

not, dust may accumulate on the printout. This may have

an influence on the picture quality.

Cleaning

roller

Be sure to hold the

maintenance door open

while cleaning the roller.

Cleaning roller

Fan cover

Filter

Reset the filter on the fan cover correctly.
