Ada shooter 400 [11/34] Sh oo ter 400

MEASUREMENT FOUNDATION

SHOOTER 400

5.4 How to operate the Laser Speed Finder. When «Speed Mode» is chosen, «speed» character will appear

on the top of the LCD. Shortly press the « » button and measurement of speed start.The speed data will be

displayed about 3 seconds later, otherwise it means the reection is too weak and the speed measurement is

failed,than LCD will display «----». During the period of speed measurement, always have to aim the moving

target .

When the target speed is being measured, the laser indicator « » will blink, afterward, the marker « > » on the

bottom of the LCD will keep moving, the target speed data will be displayed on the bottom of the LCD at last.

Users have to aim the moving target up to get the speed data and the direction of speed measurement needs

to be in line with the direction of the moving target as best as one can, otherwise the excessive included angle

will affect the veracity of the speed measurement as a result. In measuring the Speed. The LCD will display

as follows Figure 5. :

Figure 5

Ready

Speed

28. 9 M/S

Ready

Speed

104 KM/h
