Smart-UPS XL 3U Rack Mount 2200/3000 VA 120/230 Vac; 3000 VA 100/200 Vac User Manual 3
Introduction
Introduction
About this UPS
The APC Uninterruptible Power Supply (UPS) provides protection for electronic equipment from utility power
blackouts, brownouts, sags and surges. The UPS filters small utility line fluctuations and isolates electronic
equipment from large disturbances by internally disconnecting from utility line power. The UPS provides
continuous power from the batteries until utility power returns to safe levels or the batteries are fully
discharged.
Accessories
This UPS is equipped with an accessory SmartSlot. Refer to the APC Web site, www.apc.com for available
accessories.
If a standard accessory, such as a Network Management Card is installed on this UPS, refer to the accessory
user manual or CD for installation and operation instructions.
Install accessories prior to connecting power to the UPS.
Unpack
Read the Safety Guide before installing the UPS.
Inspect the UPS upon receipt. Notify the carrier and dealer if there is damage.
The packaging is recyclable; save it for reuse or dispose of it properly.
Check the package contents:
NOTE: The model and serial numbers are located on a small, rear panel label. For some models, an
additional label is located on the chassis under the front bezel.
•UPS
• Front bezel
• Rail kit
• EPO connectors
120 V Models Only:
UPS literature kit contents:
• Two rack-mount brackets
• Four cage nuts
• Eight flathead screws
• Product documentation
• Smart-UPS® User Manuals CD
• PowerChute® Business Edition CD
• Serial and USB communication cable
• Safety information
• Warranty information
100/200 V Models Only:
UPS literature kit contents:
• Two rack-mount brackets
• Four cage nuts
• Eight flathead screws
• Product documentation
• Serial communication cable
• Safety information
• Warranty information
230 V Models Only:
UPS literature kit contents:
• Two rack-mount brackets
• Four cage nuts
• Eight flathead screws
• Product documentation
• Smart-UPS® User Manuals CD
• PowerChute® Business Edition CD
• Serial and USB communication cable
• Safety information
• Warranty information
• Input power cord
• Alternate input power cord
(UK customers)
• Utility connector plug
• IEC jumper cables
