APC smart-ups srt5kxli [12/35] Key to identify rear panel features
![APC smart-ups srt5kxli [12/35] Key to identify rear panel features](/views2/1159294/page12/bgc.png)
Smart-UPS On-Line SRT5K/6K Tower/Rack-Mount 3U/4U10
Key to identify rear panel features
SmartSlot The SmartSlot can be used to connect optional management accessories.
External battery
power and
communication
connector
Use the external battery cable on the XLBP to connect the UPS and XLBP.
XLBPs provide extended runtime during power outages. The UPS will automatically recognize
up to 10 external battery packs.
Chassis ground
screws
The UPS and XLBPs have ground screws for connecting the ground leads. Prior to connecting a
ground lead, disconnect the UPS from mains power.
Hardwire output
box
SRT5KRMXLW-HW, SRT6KXLI, SRT6KRMXLI, SRT6KXLT, SRT6KRMXLT,
SRT6KXLT-IEC, SRT6KRMXLT-IEC models are equipped with a hardwire output box.
Refer to “Wiring Specifications” on page 11 for hardwire specifications.
Remove the knockouts. Snap-In strain reliefs are recommended (not supplied).
EPO terminal The Emergency Power Off (EPO) terminal allows the user to connect the UPS to a central EPO
system.
Serial Com The Serial Com port is used to communicate with the UPS.
Use only interface kits supplied or approved by APC by Schneider Electric. Any other
serial interface cable will be incompatible with the UPS connector.
USB port The USB port is used to connect either a server for native operating system communications, or
for software to communicate with the UPS.
Note: Serial and USB communication should not be used simultaneously. Use either the Serial
Com or the USB port.
Universal I/O port Use to connect:
• Temperature sensor AP9335T (supplied)
• Temperature/humidity sensor AP9335TH (not supplied)
• Relay input/output connector AP9810 (not supplied), supports two input contacts and one
output relay
Console port Use the Console port to configure the network management features.
Network port Use the Network port to connect the UPS to the network.
Reset button Use the Reset button to restart the Network Management Interface.
Note: A restart of the Network Management Interface does not affect UPS operation.
AC input
power cable or
hardwire input box
• SRT5KXLT, SRT5KRMXLT, SRT5KXLT-IEC, SRT5KRMXLT-IEC models have factory
installed input power cables.
• All other models are equipped with a hardwire input box.
Refer to “Wiring Specifications” on page 11.
Remove the knockouts. Snap-In strain reliefs are recommended (not supplied).
Controllable outlet
group 1
Connect electronic devices to these outlets.
Controllable outlet
group 2
Connect electronic devices to these outlets.
Controllable outlet
group 3
Connect electronic devices to these outlets.
Circuit breaker In the event an overload condition occurs, disconnect nonessential equipment.
Then reset the circuit breaker.
