10
English
No. Description
1 Power Fan Connector (PWR_FAN1)
2 CPU Fan Connector (CPU_FAN2)
3 CPU Fan Connector (CPU_FAN1)
4 ATX 12V Power Connector (ATX12V1)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6 ATX Power Connector (ATXPWR1)
7 USB 3.0 Header (USB3_2_3)
8 SATA2 Connector (SATA2_5)
9 SATA2 Connector (SATA2_4)
10 SATA3 Connector (SATA3_2)
11 SATA3 Connector (SATA3_0)
12 Chassis Speaker Header (SPEAKER1)
13 SATA3 Connector (SATA3_1)
14 SATA3 Connector (SATA3_3)
15 System Panel Header (PANEL1)
16 USB 2.0 Header (USB6_7)
17 USB 2.0 Header (USB4_5)
18 Chassis Fan Connector (CHA_FAN1)
19 Chassis Intrusion Header (CI1)
20 Infrared Module Header (IR1)
21 TPM Header (TPMS1)
22 Front Panel Audio Header (HD_AUDIO1)
23 Clear CMOS Jumper (CLRCMOS1)
24 Chassis Fan Connector (CHA_FAN2)
