ASRock 960gm-vgs3 fx [41/53] Cpu configuration
![ASRock 960gm-vgs3 fx [41/53] Cpu configuration](/views2/1159414/page41/bg29.png)
41
Cool ‘n’ Quiet
Use this item to enable or disable AMD’s Cool ‘n’ Quiet
TM
technology. The
default value is [Enabled]. Conguration options: [Enabled] and [Disabled].
If you install Windows
®
8 / 7 / Vista
TM
and want to enable this function,
please set this item to [Enabled]. Please note that enabling this function
may reduce CPU voltage and memory frequency, and lead to system sta-
bility or compatibility issue with some memory modules or power supplies.
Please set this item to [Disable] if above issue occurs.
Secure Virtual Machine
When this option is set to [Enabled], a VMM (Virtual Machine Architecture)
can utilize the additional hardware capabilities provided by AMD-V. The
default value is [Enabled]. Conguration options: [Enabled] and [Disabled].
Enhance Halt State (C1E)
All processors support the Halt State (C1). The C1 state is supported
through the native processor instructions HLT and MWAIT and requires no
hardware support from the chipset. In the C1 power state, the processor
maintains the context of the system caches.
CPU Thermal Throttle
Use this item to enable CPU internal thermal control mechanism to keep
the CPU from overheated. The default value is [Auto].
3.4.1 CPU Conguration
BIOS SETUP UTILITY
CPU Configuration
Select Scre en
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatr ends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Cool' n' Quiet
[Enabled]
Secure Virtual Machine
Enhanced Halt State(C1E)
CPU Thermal Throttle
[Enabled]
[Disabled]
[Auto]
