47
3.4.6 Super IO Conguration
Serial Port Address
Use this item to set the address for the onboard serial port. Conguration
options: [3F8 / IRQ4] and [3E8 / IRQ4].
Infrared Port
Use this item to enable or disable the onboard infrared port.
Infrared Port Address
Use this item to set the address for the onboard infrared port.Conguration
options: [2F8 / IRQ3] and [2E8 / IRQ3].
Parallel Port Address
Use this item to set the address for the onboard parallel port.
Conguration options: [378] and [278].
Parallel Port Mode
Use this item to set the operation mode of the parallel port. The default
value is [ECP+EPP]. If this option is set to [ECP+EPP], it will show the
EPP version in the following item, “EPP Version”. Conguration op-
tions: [Normal], [Bi-Directional] and [ECP+EPP].
EPP Version
Use this item to set the EPP version. Conguration options: [1.9]
and [1.7].
ECP Mode DMA Channel
Use this item to set the ECP mode DMA channel. Conguration
options: [DMA0], [DMA1] and [DMA3].
Parallel Port IRQ
Use this item to set the IRQ for the parallel port. Conguration options:
[IRQ5] and [IRQ7].
BIOS SETUP UTILITY
Configure Super IO Chipset
A llow BIOS to Enable
o r Disable Floppy
C ontroller.
S elect S creen
S elect I tem
+ - C hange Option
F 1 G eneral Help
F 9 L oad Defaults
F 10 S ave and Exit
E SC E xit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
S erial Port A ddress
I nfrared Port Address
P arallel Port Address
P arallel Port Mode
E PP Version
E CP Mode UMA Channel
P arallel Port IRQ
[ 3F8 / IRQ4]
[ Disabled]
[ 378]
[ ECP+EPP]
[ 1.9]
[ DMA3]
[ IRQ7]
