Fatal1ty FM2A88X+ Killer Series
5
English
Storage
• 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID
0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot
Plug
Connec-
tor
• 1 x COM Port Header
• 1 x Chassis Intrusion Header
• 1 x TPM Header
• 1 x Power LED Header
• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
• 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
• 1 x Power Fan Connector (3-pin)
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector (Hi-Density Power Con-
nector)
• 1 x SLI/XFire Power Connector
• 1 x Front Panel Audio Connector
• 3 x USB 2.0 Headers (Support 6 USB 2.0 ports)
• 1 x USB 3.0 Header by AMD A88X (Bolton-D4) (Sup-
ports 2 USB 3.0 ports)
BIOS
Feature
• 64Mb AMI UEFI Legal BIOS with GUI support
• Supports “Plug and Play”
• ACPI 1.1 Compliant wake up events
• Supports jumperfree
• SMBIOS 2.3.1 support
• DRAM, VDDP, VDDR Voltage multi-adjustment
Support
CD
• Drivers, Utilities, AntiVirus Software (Trial version),
Google Chrome Browser and Toolbar, Start8 (30 days
trial), XSplit, Killer Network Manager
Hardware
Monitor
• CPU temperature sensing
• Chassis temperature sensing
• CPU Fan Tachometer
• Chassis Fan Tachometer
• CPU/Chassis Quiet Fan
• CPU/Chassis Fan multi-speed control
• CASE OPEN detection
• Voltage monitoring: +12V, +5V, +3.3V, Vcore
