8
English
1.4 I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB01) 9 Front Speaker (Lime)**
2 D-Sub Port 10 Microphone (Pink)
3 Fatal1ty Mouse Port (USB2) 11 Optical SPDIF Out Port
4 USB 2.0 Port (USB3) 12 USB 3.0 Ports (USB3_2_3)
5 LAN RJ-45 Port* 13 USB 3.0 Ports (USB3_0_1)
6 Central / Bass (Orange) 14 HDMI Port
7 Rear Speaker (Black) 15 DVI-D Port
8 Line In (Light Blue) 16 PS/2 Mouse/Keyboard Port
1 2 4
3
5 7
101116 12131415
6
9
8
