ASRock z97 pro4 [31/99] English
![ASRock z97 pro4 [31/99] English](/views2/1159425/page31/bg1f.png)
25
English
Z97 Pro4
Step 3
Connect a VGA cable or a DVI cable to the
monitor connector or the DVI connec-
tor of the graphics card that is inserted to
PCIE1 slot.
