2
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
All Solid Capacitor design
•
High Density Glass Fabric PCB
CPU
•
Intel® Quad-Core Pentium® Processor J2900 (2.41 GHz)
Memory
•
Dual Channel DDR3/DDR3L Memory Technology
•
2 x DDR3/DDR3L DIMM Slots
•
Supports DDR3/DDR3L 1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 16GB
(see CAUTION)
* If only one DIMM module is installed, please install it into
DDR3_A1.
Expansion
Slot
•
1 x PCI Express 2.0 x16 Slot (PCIE2 @ x1 mode)
•
2 x PCI Express 2.0 x1 Slots
Graphics
•
Intel
®
7
th
generation (Gen 7) graphics
•
DirectX 11.0, Pixel Shader 5.0
•
ree graphics output options: D-Sub, DVI-D and HDMI
•
Supports HDMI Technology with max. resolution up to
1920x1200 @ 60Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Port (Compliant
HDMI monitor is required)
•
Supports HDCP with DVI-D and HDMI Ports
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
and HDMI Ports
Audio
•
5.1 CH HD Audio (Realtek ALC662 Audio Codec)
•
Supports Surge Protection (ASRock Full Spike Protection)
