8
* There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indica-
tions.
Activity / Link LED Speed LED
Status Description Status Description
Off No Link Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
To enable Multi-Streaming function, you need to connect a front panel audio
cable to the front panel audio header. Please refer to below steps for the
software setting of Multi-Streaming. After restarting your computer, please
double-click “Realtek HD Audio Manager” on the system tray. Set “Speaker
-
audio streams simultaneously”, and click “ok”. Then reboot your system.
