HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
Storage
•
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x M.2_SSD (NGFF) Socket 3, supports M.2 SATA3 6.0
Gb/s module and M.2 PCI Express module up to Gen2 x4
(20 Gb/s) (M.2_SSD (NGFF) Socket 3 is shared with the
SATA3_0 connector)
Connector
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Power LED Header
•
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
•
3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
•
1 x Power Fan Connector (3-pin)
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector
•
2 x PCIe Power Connectors
•
1 x Front Panel Audio Connector
•
1 x SPDIF Out Connector
•
3 x USB 2.0 Headers (Support 6 USB 2.0 ports) (Supports ESD
Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header by ASMedia ASM1042A (Supports 2
USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike
Protection))
BIOS
Feature
•
32Mb AMI UEFI Legal BIOS with with GUI support
•
Supports “Plug and Play”
•
ACPI 1.1 Compliant wake up events
•
Supports jumperfree
•
SMBIOS 2.3.1 support
•
CPU, VCCM, NB, SB Voltage multi-adjustment
