![ASRock n3150dc-itx [11/56] English](/views2/1159590/page11/bgb.png)
6
English
N3150DC-ITX
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 204-pin DDR3 SO-DIMM Slot (DDR3_B1)
3 204-pin DDR3 SO-DIMM Slot (DDR3_A1)
4 SATA Power Connector (SATA_PWR1)
5 SATA Power Connector (SATA_PWR2)
6 USB 3.0 Header (USB3_3_4)
7 USB 2.0 Header (USB_5_6)
8 Chassis Fan Connector (CHA_FAN1)
9 USB 2.0 Header (USB_3_4)
10 SATA3 Connector (SATA3_1)
11 SATA3 Connector (SATA3_2)
12 Chassis Speaker Header (SPEAKER1)
13 System Panel Header (PANEL1)
14 Clear CMOS Jumper (CLRMOS1)
15 COM Port Header (COM1)
16 SATA3 Connector (SATA3_A2)
17 SATA3 Connector (SATA3_A1)
18 Chassis Intrusion Header (CI1)
19 Print Port Header (LPT1)
20 TPM Header (TPMS1)
21 SPDIF Out Connector (SPDIF_OUT1)
22 Front Panel Audio Header (HD_AUDIO1)
