xii
Package contents
Check your motherboard package for the following items.
Z77-A
ASUS Z77-A motherboard
2 x Serial ATA 6.0 Gb/s
cables
User Guide
1 x I/O Shield User Guide Support DVD
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may vary
with different models.
