2-22
Chapter 2: Getting started
Graphics Conguration
Allows you to select a primary display from iGPU, and PCIe graphical devices.
Primary Display [Auto]
Allows you to select which of the iGPU/PCIE Graphics device should be the Primary
Display. Conguration options: [Auto] [iGPU] [PCIE] [PCI]
iGPU Memory [Auto]
Allows you to select the amount of system memory allocated to DVMT 5.0 used by the
iGPU. Conguration options: [Auto] [32M]~[1024M]
Render Standby [Enabled]
Allows you to enable the Intel
®
Graphics Render Standby support to reduce the iGPU
power use when idle. Conguration options: [Disabled] [Enabled]
iGPU Multi-Monitor [Disabled]
Allows you to enable the iGPU Multi-Monitor. For Lucid Virtu MVP function supports,
set this item to [Enabled] to empower both integrated and discrete graphics. iGPU
shared system memory size is xed in 64MB.
Conguration options: [Disabled] [Enabled]
NB PCIe Conguration
Allows you to congure the NB PCI Express settings.
PCIEx16 Link Speed [Auto]
Allows you to congure the PCIEx16 speed.
Conguration options: [Auto] [Gen1] [Gen2] [Gen3]
2.5.5 AMT Conguration
The items in this menu allow you to change the Intel
®
Active Management Technology (AMT)
feature.
Intel
®
AMT [Enabled]
Allow you to enable or disable the Intel
®
Active Management Technology (AMT) in the BIOS
extension. Conguration options: [Enabled] [Disabled]
• iAMT H/W is always enabled. This option just controls the BIOS extension execution.
If enabled, this requires additional rmware in the SPI device.
• The following two items become congurable only when you set the Intel
®
AMT item to
[Enabled].
Invoke MEBx [Disabled]
This item become congurable only when the previous item is set to [Enabled] and allows
you to enable or disable this function. Conguration options: [Enabled] [Disabled]
Un-Congure ME [Disabled]
Sets this item to [Disabled] to uncongure AMT/ME without using a password or set it to
[Enabled] to use a password. Conguration options: [Enabled] [Disabled]
