vii
PIKE 2108 specications summary
* The exact OS support would base on the OS support list of the motherboard.
** Specications are subject to change without notice.
Controller LSI SAS 2108 6Gb/s SAS Controller
Interface ASUS PIKE interface
Ports 8 ports
Support Device SAS / SAS II devices
SATA / SATA II / SATA III devices
Data transfer rate SATA III and SAS II 6Gb/s per PHY
RAID level • RAID 0 / 1 / 10 / 5 / 50 / 6 / 60
• Max. physical Disk qty for RAID: 16
Cache 512MB DDR2 800MHz onboard SDRAM
Battery Backup Support Header reserved for LSI Standard BBU (acquired from
LSI existing distribution channel)
OS support* Windows
®
XP Professional SP3
Windows
®
Server 2003 SP2 Enterprise Edition
Windows
®
Server 2003 SP2 Standard Edition
Windows
®
Server 2008 Enterprise Edition SP2
Windows
®
Server 2008 Enterprise Edition R2
Windows
®
Server 2008 Standard Edition SP2
Windows
®
Server 2008 Standard Edition R2
Windows
®
7 (Ultimate)
Red Hat
Enterprise Linux AS 4.8
Red Hat
Enterprise Linux AS 5.5
SuSE Linux Enterprise Server 10.3
SuSE Linux Enterprise Server 11.1
Fedora 12
Free BSD 8.1
Cent OS 5.5
ESX4.0 UP1
ESXi4.0
Form factor 6.44 in x 1.57 in (1U compatible)
