Asus z9pe-d16 Инструкция по эксплуатации онлайн
Содержание
- First edition v1 december 2011 2
- Chapter 1 product introduction 3
- Chapter 2 hardware information 3
- Contents 3
- Chapter 3 powering up 4
- Chapter 4 bios setup 4
- Contents 4
- Chapter 5 raid configuration 5
- Contents 5
- Appendix reference information 6
- Chapter 6 driver installation 6
- Contents 6
- Canadian department of communications statement 7
- Federal communications commission statement 7
- Notices 7
- Electrical safety 8
- Operation safety 8
- Safety information 8
- About this guide 9
- How this guide is organized 9
- Where to find more information 9
- Conventions used in this guide 10
- Typography 10
- Z9pe d16 specifications summary 11
- Z9pe d16 specifications summary 12
- Chapter summary 14
- Before you start installing the motherboard and hardware devices on it check the items in your package with the list below 15
- Check your motherboard package for the following items 15
- Package contents 15
- Thank you for buying an asus 15
- The motherboard delivers a host of new features and latest technologies making it another standout in the long line of asus quality motherboards 15
- Welcome 15
- Z9pe d16 15
- Z9pe d16 motherboard 15
- Latest processor technology 16
- Optimized inte 16
- Product highlights 16
- Serial number label 16
- Special features 16
- Turbo boost technology 16
- Upgrade kit table for intel scu 16
- Ddr3 memory support 17
- Enhanced intel speedstep technology eist 17
- Hyper threading 17
- I350 gigabit lan solution 17
- Pcie 3 17
- Serial ata ii technology 17
- Asus fan speed control technology 18
- Asus mio audio card 18
- Innovative asus features 18
- Pike proprietary i o kit expansion 18
- Serial ata iii technology 18
- Temperature fan and voltage monitoring 18
- Usb 2 technology 18
- Hardware 19
- Information 19
- Chapter summary 20
- Before you proceed 21
- Standby power led sb_pwr1 21
- The motherboard comes with a standby power led the green led lights up to indicate the system ac power cable plug or not this is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component the illustration below shows the location of the onboard led 21
- Motherboard overview 22
- Placement direction 22
- Screw holes 22
- Asus z9pe d16 2 5 23
- Bmc_led 23
- Err_cpu1 23
- Err_cpu2 23
- Motherboard layout 23
- Z9pe d16 23
- Layout contents 24
- Central processing unit cpu 26
- Installing the cpu 26
- Locate the cpu socket on the motherboard 26
- The motherboard comes with a surface mount lga2011 socket designed for the intel 26
- To install a cpu 26
- Xeon e5 2600 family processor 26
- Apply some thermal interface material to the exposed area of the cpu that the heatsink will be in contact with ensuring that it is spread in an even thin layer 30
- Connect the cpu fan cable to the connector on the motherboard labeled 30
- Cpu_fan1 cpu_fan2 30
- A ddr3 module has the same physical dimensions as a ddr2 dimm but is notched differently to prevent installation on a ddr2 dimm socket ddr3 modules are developed for better performance with less power consumption 31
- Gb 16gb and 32gb lr dimms into the dimm sockets using the memory configurations in this section 31
- Memory configurations 31
- Overview 31
- System memory 31
- The figure illustrates the location of the ddr3 dimm sockets 31
- The motherboard comes with eight per cpu double data rate 3 ddr3 dual inline memory modules dimm sockets 31
- You may install 1gb 2gb 4gb 8gb 16gb and 32gb rdimms or 31
- Installing a dimm on a single clip dimm socket 33
- Removing a dimm from a single clip dimm socket 33
- Configuring an expansion card 34
- Expansion slots 34
- Installing an expansion card 34
- Interrupt assignments 35
- Pci express x16 slot x16 link 35
- Pci express x16 slot x8 link 35
- Pike slots 35
- Standard interrupt assignments 35
- The onboard pcie 3 and 5 provide one x16 gen3 link to cpu2 the onboard pcie 4 provide one x16 gen3 link to cpu1 the onboard pcie 2 provide one x16 gen3 link to cpu1 auto switch to x8 link if pcie 1 is occupied these slots support vga cards and various server class high performance add on cards 35
- The onboard pcie 6 provides one x8 link to cpu2 the onboard pcie 1 slots provide one x8 gen3 link to cpu1 mio supported these slot supports vga cards and various server class high performance add on cards 35
- The pike slot allows you to choose and change your preferred sas solution easily install an optional asus pike raid card based on your needs 35
- 18 chapter 2 hardware information 36
- Connect the asrk module to the connector 37
- Connecting the asrk module optional 37
- Follow the steps below to connect the asrk module to the connector on your motherboard 37
- Locate the asrk connector on the motherboard 37
- Installing an asus pike raid card 38
- Installing asmb6 management board 39
- Jumpers 40
- Connectors 44
- Dm_lan1 port led indications 44
- Rear panel connectors 44
- Asrk module these connectors are for the sas signal 45
- Cables for sas hard disk drives that allows up to 3gb s of data transfer rate 45
- If you installed sas hard disk drives you can create a raid 0 raid 1 raid 10 or raid 5 asrk 2 5 6 9 supported only configuration 45
- Internal connectors 45
- Isas connectors 7 pin isas1 4 gray 7 pin isas5 8 black 45
- Lan port led indications 45
- Supported by the intel supported by the intel 45
- Eatx power connectors 24 pin eatxpwr1 8 pin eatx12v1 eatx12v2 psusmb1 50
- These connectors are for an eatx power supply plugs the power supply plugs are designed to fit these connectors in only one orientation find the proper orientation and push down firmly until the connectors completely fit 50
- 1 front panel smb 6 1 pin fpsmb 52
- 2 lan activity led 2 pin lan13_led lan24_led 52
- 3 chassis intrusion 4 1 pin chassis 52
- 34 chapter 2 hardware information 52
- 4 locator led 2 pin locatorled1 and 2 pin locatorled2 52
- 5 locator button swich 2 pin locatorbtn 52
- Auxiliary panel connector 20 2 pin aux_panel1 52
- These leads are for gigabit lan activity leds on the front panel 52
- These leads are for the intrusion detection feature for chassis with intrusion sensor or microswitch when you remove any chassis component the sensor triggers and sends a high level signal to these leads to record a chassis intrusion event the default setting is short caseopen and gnd pin by jumper cap to disable the function 52
- These leads are for the locator button on the front panel this button queries the state of the system locator 52
- These leads are for the locator led1 and led2 on the front panel connect the locator led cables to these 2 pin connector the leds will light up when the locator button is pressed 52
- These leads connect the front panel smbus cable 52
- This connector is for additional front panel features including front panel smb locator led and switch chassis intrusion and lan leds 52
- Powering up 53
- Chapter summary 54
- Starting up for the first time 55
- Powering off the computer 56
- Using the dual function power switch 56
- Using the os shut down function 56
- Bios setup 57
- Chapter summary 58
- Asus crashfree bios 3 utility 59
- Managing and updating your bios 59
- Recovering the bios from a usb flash drive 59
- Asus ez flash 2 utility 60
- Bupdater utility 61
- Updating the bios file 61
- 6 chapter 4 bios setup 62
- Do not shut down or reset the system while updating the bios to prevent system boot failure 62
- The bios update is finished please restart your system 62
- The utility returns to the dos prompt after the bios update process is completed reboot the system from the hard disk drive 62
- The utility verifies the file then starts updating the bios file 62
- Bios setup program 63
- 8 chapter 4 bios setup 64
- Advanced for changing the advanced system settings 64
- Bios menu screen 64
- Boot for changing the system boot configuration 64
- Event logs for changing the event log settings 64
- Exit for selecting the exit options 64
- Main for changing the basic system configuration 64
- Menu bar 64
- Monitor for displaying the system temperature power status and changing the fan settings 64
- Security for changing the security settings 64
- Server mgmt for changing the server mgmt settings 64
- The menu bar on top of the screen has the following main items 64
- To select an item on the menu bar press the right or left arrow key on the keyboard until the desired item is highlighted 64
- Tool for configuring options for special functions 64
- Configuration fields 65
- General help 65
- Menu items 65
- Navigation keys 65
- Pop up window 65
- Scroll bar 65
- Submenu items 65
- 10 chapter 4 bios setup 66
- Allows you to set the system date 66
- Allows you to set the system time 66
- Main menu 66
- System date day xx xx xxxx 66
- System time xx xx xx 66
- When you enter the bios setup program the main menu screen appears the main menu provides you an overview of the basic system information and allows you to set the system date time settings 66
- Advanced menu 67
- Asus z9pe d16 4 11 67
- Cpu configuration 67
- Take caution when changing the settings of the advanced menu items incorrect field values can cause the system to malfunction 67
- The advanced menu items allow you to change the settings for the cpu and other system devices 67
- 12 chapter 4 bios setup 68
- Active processor cores all 68
- Adjacent cache line prefetch enabled 68
- Allows you to enable or disable the intel hyper threading technology function when disabled only one thread per activated core is enabled configuration options disabled enabled 68
- Configuration options all 1 2 3 4 5 6 7 68
- Enter to view socket soecific cpu information 68
- Execute disable bit enabled 68
- Hardware prefetcher enabled 68
- Hyper threading enabled 68
- Limit cpuid maximum disabled 68
- Server class custom 68
- Setting this item to enabled allows legacy operating system to boot even without support for cpus with extended cpuid functions configuration options disabled enabled 68
- Socket 1 cpu information 68
- This item allows you to turn on off prefetching of adjacent cache lines configuration options disabled enabled 68
- This item allows you to turn on off the mid level cache l2 streamer prefetcher configuration options disabled enabled 68
- Use intel recommended prefetch settings configuration options enterprise high performance hpc custom 68
- Xp can prevent certain classes of malicious buffer overflow attacks when combined with a supporting os windows server 2003 sp1 windows xp sp2 suse linux 9 redhat enterprise 3 update 3 configuration options disabled enabled 68
- Asus z9pe d16 4 13 69
- Configuration options disabled enabled 69
- Cpu power management configuration 69
- Dcu ip prefetcher enabled 69
- Dcu streamer prefetcher enabled 69
- Eist enabled 69
- Intel virtualization technology enabled 69
- P state coordination hw_all 69
- Power technology custom 69
- This item allows you to change p state coordination type configuration options hw_all sw_all sw_any 69
- This item allows you to enabled disabled intel speedstep configuration options disabled enabled 69
- This item allows you to enabled disabled l1 data prefetcher configuration options disabled enabled 69
- This item allows you to enabled power management features configuration options disabled energy efficient custom 69
- Turbo mode enabled 69
- When enabled this item a vmm can utilize the additional hardware capabilities provided by vanderpool technology configuration options disabled enabled 69
- Cpu c3 report disabled 70
- Cpu c6 report enabled 70
- Cpu c7 report disabled 70
- Factory long duratiion maintained 1000 ms 70
- Factory long duratiion power limit 115 watts 70
- Long duation power limit 0 70
- Package c state limit c6 70
- Recommended short duration power1 1 5 long duraton 70
- Short duation power limit 0 70
- Asus z9pe d16 4 15 71
- Chipset configuration 71
- Configuration options disabled enabled 71
- Isoc enabled 71
- Qpi configuration 71
- Qpi link frequency select auto 71
- Qpi link speed mode fast 71
- Qpi link0p disabled 71
- Qpi link0s disabled 71
- Qpi link1 enabled 71
- This item allows for selecting the qpi link frequency configuration options auto 6 gt s 7 gt s fast mode only 8 gt s fast mode only 71
- This item allows you to select the qpi link speed as either the fast mode or slow mode configuration options slow fast 71
- 16 chapter 4 bios setup 72
- Channel interleaving auto 72
- Compatibility rid enabled 72
- Ddr speed auto 72
- Force ddr speed configuration options auto force ddr3 800 force ddr3 1066 force ddr3 1333 force ddr3 1600 force ddr3 1866 72
- Memory configuration 72
- Memory mode independent 72
- Rank interleaving auto 72
- Scroll down to display the following items 72
- Select different channel interleaving setting configuration options auto 1 way 2 way 3 way 4 way 72
- Select different rank interleaving setting configuration options auto 1 way 2 way 4 way 8 way 72
- Select the mode for memory initializaton configuration options independent mirroring lock step sparing 72
- Support for compatibility revision id crid functionality mentioned in sandybridge bios spec configuration options enabled disabled 72
- Allow 2x refresh enabled 73
- Altitude 300 m 73
- Data scrambling enabled 73
- Demand scrub enabled 73
- Device tagging disabled 73
- Enable high temp disabled 73
- Memory hot sensor support enabled 73
- Patrol scrub disabled 73
- Thermal throtting cltt 73
- 18 chapter 4 bios setup 74
- Allows to decide priority between onboard and 1st offboard video device found configuration options onboard offboard 74
- Allows to enabled disabled direct cache access support configuration options disabled enabled 74
- Allows to enabled disabled intel i o accelaration technology configuration options disabled enabled 74
- Cpu iio bridge configuration 74
- Dca support enabled 74
- Dimm information 74
- Intel r i oat disabled 74
- Targetvga 74
- Vga priority offboard 74
- Allows to enabled disabled azalia hd audio 75
- Allows to enabled disabled high precision event timer 75
- Allows to enabled disabled onboard sata raid option rom if launch storage oprom is enabled configuration options disabled enabled 75
- Asus z9pe d16 4 19 75
- Audio configuration 75
- Azalia hd audio enabled 75
- Configuration options disabled enabled 75
- Configuration options disabled enabled in s5 enabled in s4 and s5 75
- Deep sx disabled 75
- High precision event timer configuration 75
- High precision timer enabled 75
- Onboard sata raid oprom enabled 75
- Pch compatibility rid disabled 75
- Pch configuration 75
- Support for pch compatibility configuration options disabled enabled 75
- Intel r vt d disabled 76
- Intel r vt for directed i o configuration 76
- Allows you to set the sata configuration configuration options disabled ide mode ahci mode raid mode 77
- Asus z9pe d16 4 21 77
- If you want the serial ata hard disk drives to use the advanced host controller interface ahci set this item to ahci mode the ahci allows the onboard storage driver to enable advanced serial ata features that increases storage performance on random workloads by allowing the drive to internally optimize the order of commands 77
- If you want to create raid sets with lsi megaraid utility or intel 77
- If you want to use the serial ata hard disk drives as parallel ata physical storage devices keep the default setting ide mode 77
- Pch sata configuration 77
- Sata mode ide mode 77
- Serial ata controller 0 enhanced 77
- Serial ata controller 1 enhanced 77
- Storage technology enterprise from the serial ata hard disk drives set this item to raid mode 77
- This item appears only when you set the sata mode item to ide mode set to enhanced to support two sata 3 gb s devices configuration options disabled enhanced 77
- This item appears only when you set the sata mode item to ide mode set to enhanced to support two sata 6 gb s and two sata 3 gb s devices set to compatible when using windows 98 nt 2000 ms dos up to four sata devices are supported under these operating systems configuration options disabled enhanced compatible 77
- 22 chapter 4 bios setup 78
- Here are the two kinds of h w configuration mentioned above 78
- Kinds of h w configuration the user can set sata only raid5 as enabled to have raid 5 supported with sata hard drives but the sas hard drive cannot be supported when this function is enabled 78
- Pch scu sas configuration 78
- Rate sata raid5 support requires additional bios setting with below two 78
- S m a r t self monitoring analysis and reporting technology is a monitor system when read write of your hard disk errors occur this feature allows the hard disk to report warning messages during the post configuration options enabled disabled 78
- S m a r t status check enabled 78
- The pch of the motherboard is hard sku a with asrk 1 or asrk 5 enabled 78
- The pch of the motherboard is hard sku b or d 78
- The pch scu sas configuration items appears only when you installed the asrk module optional on the motherboard this menu automatically detects and displays the device 1 8 intel 78
- Asus z9pe d16 4 23 79
- Enables or disables pci device to generate perr configuration options disabled enabled 79
- Enables or disables pci device to generate serr configuration options disabled enabled 79
- Enables or disables pci device to load rt32 image configuration options disabled enabled 79
- Enables or disables vga pallette registers snooping configuration options disabled enabled 79
- In case of multiple option roms legacy and efi compatible specifies what pci option rom to lanuch configuration options legacy rom efi compatible rom 79
- Load rt32 image disabled 79
- Pci latency timer 32 pci bus clocks 79
- Pci rom priority efi compatible rom 79
- Pci subsystem settings 79
- Perr generation disabled 79
- Serr generation disabled 79
- Value to be programmed into pci latency timer register configuration options 32 pci bus clocks 64 pci bus clocks 96 pci bus clocks 128 pci bus clocks 160 pci bus clocks 192 pci bus clocks 224 pci bus clocks 248 pci bus clocks 79
- Vga palette snoop disabled 79
- 24 chapter 4 bios setup 80
- Allows to set the aspm level configuration options disabled auot force l0s force l0s force all links to l0s state auto bios auto configure disabled disabled aspm 80
- Aspm support disabled 80
- Pci express link register settings 80
- Pci express settings 80
- Asus z9pe d16 4 25 81
- Configuration options disabled enabled 81
- Enables or disables boot option for legacy mass storage device with option rom 81
- Launch storage 0prom enabled 81
- Pcie slot option rom configuration 81
- Pcie1 option rom enabled 81
- Pcie2 option rom enabled 81
- Pcie3 option rom enabled 81
- Pcie4 option rom enabled 81
- Pcie5 option rom enabled 81
- Pcie6 option rom enabled 81
- Pike option rom enabled 81
- 26 chapter 4 bios setup 82
- Configuration options disabled enabled 82
- Configuration options pxe iscsi 82
- Enables or disables intel lan1 function configuration options disabled enabled 82
- Enables or disables intel lan2 function configuration options disabled enabled 82
- Enables or disables intel lan3 function configuration options disabled enabled 82
- Intel lan rom type pxe 82
- Intel lan1 enable enabled 82
- Intel lan2 enable enabled 82
- Intel lan3 enable enabled 82
- Lan1 option rom support enabled 82
- Lan2 option rom support enabled 82
- Lan3 option rom support enabled 82
- Onboard lan configuration 82
- The following item appears only when you set intel lan support to enabled 82
- Asus z9pe d16 4 27 83
- Configuration options disabled enabled 83
- Enables or disables intel lan4 function configuration options disabled enabled 83
- Enables or disables legacy usb device support configuration options enabled disabled auto 83
- Intel lan4 enable enabled 83
- Intel txt lt sx configuration 83
- Lan4 option rom support enabled 83
- Legacy usb support enabled 83
- Usb configuration 83
- Ami virtual cdrom0 1 0 auto 84
- Ami virtual floppy0 1 0 auto 84
- Ami virtual hdisk0 1 0 auto 84
- Ehci hand off disabled 84
- Mass storage devices 84
- Usb hardware delays and time outs 84
- Usb reset time out 20 sec 84
- Usb transfer time out 20 sec 84
- Allows to enable or disable onboard usb 3 4 5 6 10 configuration options disabled enabled 85
- Allows to enable or disable rear usb 1 and 2 configuration options disabled enabled 85
- Allows you to enable or disable the tpm support configuration options disabled enabled 85
- Asus z9pe d16 4 29 85
- Ehci controller 1 2 enabled 85
- Onboard usb 3 4 5 6 10 enabled 85
- Rear usb 1 and 2 enabled 85
- Tpm support enabled 85
- Trusted computing 85
- Usb configuration the usb device will all disable in os configuration options disabled enabled 85
- Usb ports configuration 85
- 30 chapter 4 bios setup 86
- Acpi settings 86
- Acpi sleep state s1 cpu stop clock 86
- Allows to enable or disable lock legacy resources configuration options disabled enabled 86
- Allows you to enable or disable bios acpi auto configuration configuration options disabled enabled 86
- Allows you to set the acpi sleep state configuration options suspend disabled s1 cpu stop clock s3 suspend to ram 86
- Enable acpi auto configuration disabled 86
- Enable hibernation enabled 86
- Enables or disables system ability to hibernate 0s s4 sleep state this option may be not effective with some os configuration options disabled enabled 86
- Lock legacy resources disabled 86
- The following item appears only when you set enabled acpi auto configuration to disabled 86
- Apm setting 87
- Power on by pcie disabled 87
- Power on by rtc disabled 87
- Restore ac power loss last state 87
- Whea configuration 87
- Whea support enabled 87
- 32 chapter 4 bios setup 88
- Ansi extended ascii char set 88
- Bits per second 57600 selects serial port transmission speed the speed must be matched on the other side long or noisy lines may require lower speeds configuration options 9600 19200 38400 57600 115200 88
- Com1 console redirection disabled 88
- Console redirection settings 88
- Enables or disables the console redirection feature configuration options disabled enabled 88
- Serial port console redirection 88
- Terminal type vt100 allows you to set the terminal type 88
- The following item appears only when you set cinsloe redirection to enabled 88
- This item becomes configurable only when you enable the console redirection item the settings specify how the host computer and the remote computer which the user is using will exchange data both computers should have the same or compatible settings 88
- Vt utf8 uses utf8 encoding to map unicode chars onto 1 or more bytes 88
- Vt100 ascii char set 88
- Vt100 extends vt100 to support color function keys et 88
- Com2 console redirection enabled 89
- Console redirection settings 89
- Console redirection disabled 90
- Console redirection settings 90
- Serial port for out of band management 90
- Windows emergency management services ems 90
- Asus z9pe d16 4 35 91
- Legacy devices configuration 91
- Me subsystem 91
- Serial port 1 2 configuration 91
- Device mode standard serial port mode 92
- Pci error logging support disabled 92
- Runtime error logging 92
- Runtime error logging support disabled 92
- Serial port enabled 92
- Allows to configure how the system should respond if the os boot watchdog timer expires not available if o s boot watchdog timer is disabled configuration options do nothing reset power down 93
- Allows to configure the length of the o s boot watchdog timer not available if o s boot watchdog timer is disabled configuration options 5 minutes 10 minutes 15 minutes 20 minutes 93
- Asus z9pe d16 4 37 93
- If enabled starts a bios timer which can only be shut off by intel management software after the os loads helps determine that the os sucessfully loaded or follows the o s boot watchdog timer policy configuration options enabled disabled 93
- O s watchdog timer disabled 93
- O s wtd timer policy reset 93
- O s wtd timer timeout 10 minutes 93
- Server mgmt menu 93
- The server mgmt menu appears only when you install asmb card on the motherboard 93
- The server mgmt menu displays the server mgmt status and allows you to change the settings 93
- 38 chapter 4 bios setup 94
- All values changed here do not take effect until computer is restarted 94
- Allows to choose options for erasing sel configuration options no yes on next reset yes on every reset 94
- Allows to choose options for reactions to a full sel configuration options do nothing erase immediately 94
- Allows you to enable or disable all features of system event logging during boot configuration options disabled enabled 94
- Custom efi logging options 94
- Erase sel no 94
- Sel components disabled 94
- System event log 94
- The following items appears only when you set sel components to enabled 94
- When sel is full do nothing 94
- Asus z9pe d16 4 39 95
- Bmc network configuration 95
- Configuration address source previous state 95
- Gateway ip address 0 allows to input gateway ip address 95
- Select to configure lan channel parameters statically or dynamically by bios or bmc unspecified option will not modify any bmc network parameters during bios phase configuration options previous state static mode dhcp mode 95
- Station ip address 0 allows to input station ip address 95
- Subnet mask 0 allows to input subnet mask 95
- The following items appears only when you set configuration address source to static mode 95
- 40 chapter 4 bios setup 96
- All values changed here do not take effect until computer is restarted 96
- Change smbios event log settings 96
- Enabling disabling options smbios event log enabled change this to enable or disable all features of smbios event logging during boot configuration options disabled enabled 96
- Erasing settings erase event log no choose options for erasing smbios event log erasing is done prior to any logging activation during reset configuration options no yes next reset yes every reset 96
- Event logs menu 96
- The event logs allows you to change or view the event log settings 96
- To change the smbios event log configuration 96
- View smbios event log 97
- View system event log 97
- 42 chapter 4 bios setup 98
- Allows option roms to trap interrupt 19 configuration options disabled enabled 98
- Allows you to enable or disable the full screen logo display feature configuration options disabled enabled 98
- Allows you to select the power on state for the numlock configuration options off on 98
- Allows you to set the display mode for options rom configuration options force bios keep current 98
- Always do not allow disable ga20 this optionis useful when any rt code is executed above 1mb 98
- Boot menu 98
- Bootup numlock state on 98
- Csm16 module version gatea20 active upon request 98
- Full screen logo enabled 98
- Interrupt 19 capture enabled 98
- Keys to adjust the number of seconds to wait for setup activation key 98
- Option rom messages force bios 98
- Set this item to enabled to use the asus mylogo2 feature 98
- Setup prompt timeout xx 98
- The boot menu items allow you to change the system boot options 98
- Upon request ga20 can be disabled using bios services 98
- Boot device seeking endless pxe 99
- Boot option priorities 99
- Uefi boot disabled 99
- 44 chapter 4 bios setup 100
- Cpu 1 2 tr1 1 2 temperature xxxºc xxxºf 100
- Cpu fan1 2 speed frnt fan1 4 speed rear fan1 2 speed xxxx rpm or ignore n a 100
- Monitor menu 100
- Scroll down to display the following items 100
- The monitor menu displays the system temperature power status and allows you to change the fan settings 100
- The onboard hardware monitor automatically detects and displays the cpu and motherboard component temperatures select ignore if you do not wish to display the detected temperatures 100
- The onboard hardware monitor automatically detects and displays the speed of cpu fans front fans and rear fan in rotations per minute rpm if the fan is not connected to the motherboard the field shows n a 100
- The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators 100
- Vtt_cpu voltage vcore1 2 voltage vddq_ab_cpu1 voltage vddq_cd_cpu1 voltage vddq_ef_cpu2 voltage vddq_gh_cpu2 voltage 5vsb voltage 5v voltage 12v voltage 3 v voltage vbat voltage 3 vsb voltage 100
- Administrator password 101
- Fan speed control generic mode 101
- Security menu 101
- Asus ez flash 2 utility 102
- Tool menu 102
- User password 102
- A confirmation window appears select yes to discard changes and exit 103
- A confirmation window appears select yes to save changes and exit 103
- Asus z9pe d16 4 47 103
- Boot override 103
- Discard changes exit 103
- Discard changes reset 103
- Exit menu 103
- From the legend bar to exit 103
- Restore defaults 103
- Save changes reset 103
- The exit menu items allow you to save or discard your changes to the bios items 103
- These items displays the available devices the device items that appears on the screen depends on the number of devices installed in the system click an item to start booting from the selected device 103
- This option allows you to reset the setup program without saving your changes when you select this option a confirmation window appears select yes to discard changes and reset 103
- This option allows you to restore load defaults values for all the setup options when you select this option a confirmation window appears select yes to load optimized defaults 103
- Configuration 105
- Chapter summary 106
- Raid definitions 107
- Setting up raid 107
- Installing hard disk drives 108
- Raid configuration utilities 108
- Setting the raid item in bios 108
- Lsi software raid configuration utility 109
- Creating a raid set 110
- Using easy configuration 110
- Asus z9pe d16 5 7 111
- Bios version a 0 9231523r 111
- Lsi software raid configuration utility ver c 5 sep 17 2010 111
- Onlin a00 00 111
- Onlin a00 01 111
- Port 2 disk 74 4gb hds728080pla380 05 1c05 111
- The information of the selected hard disk drive displays at the bottom of the screen 111
- To configure array setting 111
- To select the configurable array 111
- When selected the drive indicator changes from ready to onlin ax y where x is the array number and y is the drive number 111
- You need at least four identical hard disk drives when creating a raid 10 set 111
- You need at least two identical hard disk drives when creating a raid 1 set 111
- 148 80gb 2 64 kb online 112
- 8 chapter 5 raid configuration 112
- Again the virtual drive information appears including a virtual drive menu that allows you to change the virtual drive parameters 112
- Bios version a 0 9231523r 112
- Ld raid size stripes stripsz status 112
- Lsi software raid configuration utility ver c 5 sep 17 2010 112
- 148 80gb 2 64 kb online 113
- Asus z9pe d16 5 9 113
- Bios version a 0 9231523r 113
- Enabling dwc can improve the performance but with the risk of data loss 113
- Ld raid size stripes stripsz status 113
- Lsi software raid configuration utility ver c 5 sep 17 2010 113
- When creating a raid 1 or a raid 10 set select dwc from the virtual 113
- When creating a when creating a raid 0 set proceed to step 12 113
- 10 chapter 5 raid configuration 114
- 148 80gb 2 64 kb online 114
- Bios version a 0 9231523r 114
- Follow step 2 to 12 to configure additional virtual drives 114
- Ld raid size stripes stripsz status 114
- Lsi software raid configuration utility ver c 5 sep 17 2010 114
- To finish raid configuration when prompted to save 114
- Use cursor keys to navigate between items and press enter to select an option 114
- When finished setting the selected virtual drive configuration select accept 114
- 148 80gb 2 64 kb online 115
- Asus z9pe d16 5 11 115
- Follow step 10 to 14 of the previous section using easy configuration to create the raid set 115
- Follow step 2 to 9 of the previous section using easy configuration 115
- Ld raid size stripes stripsz status 115
- To create a raid set using the new configuration option 115
- Using new configuration 115
- When a raid set already exists using the new configuration command erases the existing raid configuration data if you do not want to delete the existing raid set use the view add configuration command to view or create another raid configuration 115
- 12 chapter 5 raid configuration 116
- Adding a new raid configuration 116
- Adding or viewing a raid configuration 116
- Follow step 3 to 12 of section 5 creating a raid set using easy configuration to add a new raid set 116
- The information of the selected hard disk drive displays at the bottom of the screen 116
- To add a new raid configuration 116
- When selected the drive indicator changes from ready to onlin ax y where x is the array number and y is the drive number 116
- You can add a new raid configuration or view an existing configuration using the view add configuration command 116
- Initializing the virtual drives 117
- Using the initialize command 117
- 100 completed 118
- 14 chapter 5 raid configuration 118
- 148 80gb 2 64 kb online 118
- Bios version a 0 9231523r 118
- Init of vd is in process 118
- Initializing a virtual drive erases all data on the drive 118
- Ld raid size stripes stripsz status 118
- Ld raid size stripes stripsz status 0 10 154494mb 4 64 kb online 118
- Lsi software raid configuration utility ver c 5 sep 17 2010 118
- Space de select f10 initialize 118
- Vd 0 initialization complete press esc 118
- Virtual drive 0 118
- Virtual drive s configured 118
- Asus z9pe d16 5 15 119
- Bios version a 0 9231523r 119
- Lsi software raid configuration utility ver c 5 sep 17 2010 119
- To initialize the virtual drives using the objects command 119
- Using the objects command 119
- 16 chapter 5 raid configuration 120
- Bios version a 0 9231523r 120
- Init will destroy data on selected vd s 120
- Initilize vd 120
- Lsi software raid configuration utility ver c 5 sep 17 2010 120
- To start initialization 120
- Asus z9pe d16 5 17 121
- Rebuilding failed drives 121
- To rebuild a failed hard disk drive 121
- You can manually rebuild failed hard disk drives using the rebuild command in the management menu 121
- 18 chapter 5 raid configuration 122
- Bios version a 0 9231523r 122
- Lsi software raid configuration utility ver c 5 sep 17 2010 122
- To rebuild the drive 122
- When rebuild is complete press any key to continue 122
- Adapter menu 123
- Asus z9pe d16 5 19 123
- Checking the drives for data consistency 123
- The check consistency command is available only for virtual drives included in a raid 1 or raid 10 set 123
- To check data consistency using the check consistency command 123
- Using the check consistency command 123
- Using the objects command 125
- 22 chapter 5 raid configuration 126
- Bios version a 0 9231523r 126
- Deleting a raid configuration 126
- Lsi software raid configuration utility ver c 5 sep 17 2010 126
- Press any key to continue 126
- The utility clears all the current array s the utility clears all the current array s 126
- To delete a raid configuration 126
- Asus z9pe d16 5 23 127
- Bios version a 0 9231523r 127
- Lsi software raid configuration utility ver c 5 sep 17 2010 127
- Selecting the boot drive from a raid set 127
- The virtual drive is selected as boot drive press any key to continue 127
- To select the boot drive from a raid set 127
- You must have created a new raid configuration before you can select the boot drive from a raid set see section 5 creating a raid set using new configuration for details 127
- 24 chapter 5 raid configuration 128
- Bios version a 0 9231523r 128
- Enabling writecache 128
- Lsi software raid configuration utility ver c 5 sep 17 2010 128
- The writecache function is recommended for raid 1 and raid 10 sets 128
- To display the adapter properties 128
- To enable writecache 128
- To turn on the option 128
- When finished press any key to continue 128
- When you enable writecache you may lose data when a power interruption occurs while transmitting or exchanging data among the drives 128
- You may manually enable the raid controller s writecache option after creating a raid set to improve the data transmission performance 128
- Enterprise scu sata option rom utility 129
- Rapid storage technology 129
- Upgrade kit table for intel scu 129
- 26 chapter 5 raid configuration 130
- If you want to use sas hdd for raid create be sure you ve already correctly installed the optional intel asrk module on the motherboard 130
- Install all the serial ata sas hard disk drives 130
- Rapid storage technology enterprise scu option rom utility 130
- The navigation keys at the bottom of the screen allow you to move through the menus and select the menu options 130
- The raid bios setup screens shown in this section are for reference only and may not exactly match the items on your screen 130
- The utility supports maximum four hard disk drives for raid configuration 130
- To display the utility main menu 130
- To enter the intel 130
- Turn on the system 130
- After completing your selection 131
- Asus z9pe d16 5 27 131
- Creating a raid set 131
- The following screen appears 131
- To create a raid set 131
- To select the hard disk drives you want to include in the raid set the select disks screen appears 131
- Creating a recovery set 132
- 30 chapter 5 raid configuration 134
- Deleting a raid set 134
- Take caution when deleting a raid set you will lose all data on the hard disk drives when you delete a raid set 134
- The following screen appears 134
- The following warning message appears 134
- To delete a raid set 134
- To return to the delete volume menu 134
- Asus z9pe d16 5 31 135
- Resetting disks to non raid 135
- Take caution before you reset a raid volume hard disk drive to non raid resetting a raid volume hard disk drive deletes all internal raid structure on the drive 135
- The following screen appears 135
- To reset a raid set hard disk drive 135
- To reset the raid set drive s a confirmation message appears 135
- To return to the utility main menu 135
- To select 135
- 32 chapter 5 raid configuration 136
- Exiting the intel 136
- If any of the sata hard disk drives included in the raid 1 array failed the system displays the status of the raid volume as degraded during post you can rebuild the raid array with other installed non raid disks 136
- Rapid storage technology utility 136
- Rebuilding the raid 136
- Rebuilding the raid with other non raid disk 136
- Select a destination disk with the same size as the original hard disk 136
- The following warning message appears 136
- This option is only for the raid 1 set 136
- To enter the intel rapid storage technology option rom utility 136
- To exit 136
- To exit the utility 136
- To rebuild the raid with other non raid disk 136
- To return to the utility main menu 136
- Rebuilding the raid with a new hard disk 137
- Setting the boot array in the bios setup utility 138
- Enterprise utility windows 139
- Rapid storage technology 139
- Creating a raid set 140
- Change volume type 142
- Delete volume 143
- E mail preferences 144
- Preferences 144
- System preferences 144
- Driver 145
- Installation 145
- Chapter summary 146
- C60x intel raid driver 147
- Creating a raid driver disk 147
- Raid driver installation 147
- Follow screen instructions to create the driver disk 148
- Locate the raid driver and place a blank high density floppy disk to the floppy disk drive 148
- Lsi 2008 sas2 driver 148
- During windows 150
- Installing the raid controller driver 150
- Server 2008 os installation 150
- Enterprise linux os 5 152
- Red hat 152
- Enterprise linux os 6 154
- Red hat 154
- Asus z9pe d16 6 11 155
- Follow the onscreen instructions to finish the os installation 155
- Insert the red ha 155
- The drivers for the raid card are installed to the system the drivers for the raid card are installed to the system 155
- 12 chapter 6 driver installation 156
- Boot the system from the suse os installation cd 156
- Suse linux 11 os 156
- To install the lsi megaraid controller driver when installing suse linux enterprise server os 156
- Use the arrow keys to select installation from the boot options menu 156
- Asus z9pe d16 6 13 157
- Sda usb floppy other device 157
- Chipset device software 159
- Installation 159
- Installation 161
- Network connections software 161
- Vga driver installation 164
- C600 series chipset sas raid 167
- Sata mode drivers 167
- Microsoft net framework 3 sp1 168
- Enterprise 3 installation 169
- Rapid storage technology 169
- I350 gigabit adapters driver 172
- Installation 172
- Drivers menu 176
- Management applications and utilities installation 176
- Place the support dvd to the optical drive the dvd automatically displays the drivers menu if autorun is enabled in your computer 176
- Running the support dvd 176
- The drivers menu shows the available device drivers if the system detects installed devices install the necessary drivers to activate the devices 176
- The support dvd that came with the motherboard package contains the drivers management applications and utilities that you can install to avail all motherboard features 176
- Contact information 177
- Make disk menu 177
- Utilities menu 177
- Reference information 179
- Appendix summary 180
- A z9pe d16 block diagram 181
- Asus computer gmbh germany and austria 183
- Asus computer international america 183
- Asus contact information 183
- Asustek computer inc china 183
- Asustek computer inc taiwan 183
- Technical support 183
- Address 800 corporate way fremon 184
- Asus computer international 184
- Ca 94539 184
- Date oct 28 2011 184
- Declaration of conformity 184
- Ec declaration of conformity 184
- Fcc part 15 subpart b unintentional radiators 184
- Fcc part 15 subpart c intentional radiators 184
- Fcc part 15 subpart e intentional radiators 184
- Hereby declares that the product 184
- Model number z9pe d16 conforms to the following specifications 184
- Per fcc part 2 section 2 1077 a 184
- Phone fax no 510 739 3777 510 608 4555 184
- Product name mother board 184
- Representative person s name representative person s name steve chang president 184
- Responsible party name responsible party name 184
- Signature 184
- Supplementary information 184
- This device complies with part 15 of the fcc rules operation is subject to the following two conditions 1 this device may not cause harmful interference and 2 this device must accept any interference received including interference that may cause undesired operation 184
Похожие устройства
- Supra SJS-12 Инструкция по эксплуатации
- Supra SJS-16 Инструкция по эксплуатации
- Asus g750jh, 90nb0182-m02020 Инструкция по эксплуатации
- Supra SCP 2-13U Инструкция по эксплуатации
- Supra SHF-102 Инструкция по эксплуатации
- Asus x550lc, 90nb02h2-m00220 Инструкция по эксплуатации
- Supra SFD-1015U Инструкция по эксплуатации
- Supra Камера заднего вида SRW-101 Инструкция по эксплуатации
- Supra STV-LC28500WL Инструкция по эксплуатации
- Supra STV-LC32T551WL Инструкция по эксплуатации
- Asus zenbook ux301la, 90nb0191-m02830 Инструкция по эксплуатации
- Asus h81m-k Инструкция по эксплуатации
- Asus h81m-d Инструкция по эксплуатации
- Asus x552ep, 90nb03qb-m00840 Инструкция по эксплуатации
- Supra SCR-74SHD Инструкция по эксплуатации
- Asus f552cl, 90nb03wb-m00360 Инструкция по эксплуатации
- Supra DRS-GD59VST Белка Инструкция по эксплуатации
- Supra BB-CD902U Инструкция по эксплуатации
- Asus me173x Инструкция по эксплуатации
- Asus tx201la Инструкция по эксплуатации
Скачать
Случайные обсуждения
