4-26 Chapter 4: BIOS setup
4.4.7 Onboard LAN Conguration
Intel LAN Enable/Disable.
Onboard LAN Conguration
Intel LAN ROM Type [PXE]
Intel LAN1 Enable [Enabled]
LAN1 Option ROM Support [Enabled]
Intel LAN2 Enable [Enabled]
LAN2 Option ROM Support [Enabled]
Intel LAN3 Enable [Enabled]
LAN3 Option ROM Support [Enabled]
Intel LAN4 Enable [Enabled]
LAN4 Option ROM Support [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Intel LAN1 Enable [Enabled]
Enables or disables Intel LAN1 function. Conguration options: [Disabled]
[Enabled]
LAN1 Option ROM Support [Enabled]
Conguration options: [Disabled] [Enabled]
Intel LAN2 Enable [Enabled]
Enables or disables Intel LAN2 function. Conguration options: [Disabled]
[Enabled]
LAN2 Option ROM Support [Enabled]
Conguration options: [Disabled] [Enabled]
Intel LAN3 Enable [Enabled]
Enables or disables Intel LAN3 function. Conguration options: [Disabled]
[Enabled]
LAN3 Option ROM Support [Enabled]
Conguration options: [Disabled] [Enabled]
The following item appears only when you set
Intel LAN Support
to [Enabled].
Intel LAN ROM Type [PXE]
Conguration options: [PXE] [iSCSI]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
