6-12 Chapter 6: Driver installation
SUSE Linux 11 OS
To install the LSI MegaRAID controller driver when installing SUSE Linux Enterprise
Server OS:
1. Boot the system from the SUSE OS installation CD.
2. Use the arrow keys to select
Installation
from the
Boot Options
menu.
F1 Help F2 Language F3 Video Mode F4 Source F5 Kernel F6 Driver
English(US) 1024 X768 DVD Default No
Boot from Hard Disk
Installation
Repair Installed System
Rescue System
Check Installation Media
Firmware Test
Memory Test
Boot Options |
3. Press <F6>, then select Yes from the menu. Press <Enter>.
F1 Help F2 Language F3 Video Mode F4 Source F5 Kernel F6 Driver
English(US) 1024 X768 DVD Default No
Boot from Hard Disk
Installation
Repair Installed System
Rescue System
Check Installation Media
Firmware Test
Memory Test
Boot Options |
Yes
No
File
URL
