4-22 Chapter 4: BIOS setup
4.4.5 PCH SCU SAS Conguration
The PCH SCU SAS conguration items appears only when you installed the
ASRK Module (optional) on the motherboard. This menu automatically detects and
displays the Device 1-8.
Intel
®
RATe SATA RAID5 support requires additional BIOS setting with below two
kinds of H/W conguration. The user can set [SATA only RAID5] as enabled to
have RAID 5 supported with SATA hard drives, but the SAS hard drive cannot be
supported when this function is enabled.
Here are the two kinds of H/W conguration mentioned above:
1. The PCH of the motherboard is hard SKU-B or -D.
or
2. The PCH of the motherboard is hard SKU-A with ASRK#1 or ASRK#5 enabled.
S.M.A.R.T. Status Check [Enabled]
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor
system. When read/write of your hard disk errors occur, this feature allows the hard
disk to report warning messages during the POST.
Conguration options: [Enabled] [Disabled]
Patsburg B/D sku only
Device1 Intel ISR10a
Device2 Intel ISR10a
Device3 Intel ISR10a
Device4 Intel ISR10a
Device5 Intel ISR10a
Device6 Intel ISR10a
Device7 Intel ISR10a
Device8 Intel ISR10a
Sata only RAID5 [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Sata only RAID5
