ASUS Z9PE-D16 4-37
4.5 Server Mgmt menu
The Server Mgmt menu displays the server mgmt status, and allows you to change
the settings.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
Wait for BMC response for
specied timeout In PILOTII,
BMC starts at the same time
when BIOS starts during AC
power ON. It takes arround
30 seconds to initialize
Host to BMC interfaces.
BMC Firmware: x.xx
O/S Watchdog Timer [Disabled]
O/S Wtd Timer Timeout [10 minutes]
O/S Wtd Timer Policy [Reset]
System Event Log
BMC network conguration
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
O/S Watchdog Timer [Disabled]
If enabled, starts a BIOS timer which can only be shut off by Intel Management
Software after the OS loads. Helps determine that the OS sucessfully loaded or
follows the
O/S Boot Watchdog TImer Policy
.
Conguration options: [Enabled] [Disabled]
O/S Wtd Timer Timeout [10 minutes]
Allows to congure the length of the O/S Boot Watchdog Timer. Not available if
O/S
Boot Watchdog Timer
is disabled.
Conguration options: [5 minutes] [10 minutes] [15 minutes] [20 minutes]
O/S Wtd Timer Policy [Reset]
Allows to congure how the system should respond if the
OS Boot Watchdog
Timer
expires. Not available if
O/S Boot Watchdog Timer
is disabled.
Conguration options: [Do Nothing] [Reset] [Power Down]
The Server Mgmt menu appears only when you install ASMB card on the
motherboard.
