4-20 Chapter 4: BIOS setup
Enables or Disables BIOS ACPI
Auto Conguration.
Intel(R) VT-d [Enabled]
Intel(R) VT-d [Disabled]
Allows you to enable or disable Intel VT-d.
Conguration options: [Enabled] [Disabled]
Intel(R) VT for Directed I/O Conguration
The following item appears only when you set
Intel(R) VT-d
to [Enabled].
Interrupt Remapping [Enabled]
Allows to enable/disable VT-d Engine Interrupt Remapping support.
Conguration options: [Disabled] [Enabled]
Coherency Support [Disabled]
Allows to enable/disable VT-d Engine Coherency support.
Conguration options: [Disabled] [Enabled]
ATS Support [Disabled]
Allows to enable/disable VT-d Engine address translation services (ATS)
support. Conguration options: [Disabled] [Enabled]
Pass-through DMA [Enabled]
Allows to enable/disable VT-d Engine pass through DMA support.
Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
