3
ASUS Xonar Phoebus
*Specications are subject to change without notice.
Items Description
I/O Ports
Analog Output Jack 3.5mm jack * 1 (Headphone out)
Analog Input Jack 3.5mm jack * 1 (Shared by Line-In / Mic-In)
Digital S/PDIF Output High-bandwidth TOS-Link combo port supports
192KHz/24bit
Other line-level analog input (for TV
Tuner or CD-ROM):
Aux-In (4-pin header on the card)
Driver Features
Operation System Windows Vista / Win 7(32/64bit) / XP(32/64bit) /
MCE2005
Dolby
®
Digital Live Dolby Digital Live encodes any audio signal on PC in
real-time to Dolby Digital (AC3) 5.1 surround sounds
to your home theater environment through one single
S/PDIF connection
Dolby
®
Headphone Dolby Headphone technology allows users to listen to
music, watch movies, or play games with the dramatic
5.1-channel surround or realistic 3D spacious effects
through any set of stereo headphones.
Dolby
®
Virtual Speaker Dolby Virtual Speaker technology simulates a highly
realistic 5.1-speaker surround sound listening
environment from as few as two speakers.
Dolby
®
Pro-Logic IIxx Dolby Pro-Logic IIx is the well-known technology to
process any native stereo or 5.1-channel audio into
a 7.1- channel output, creating a seamless, natural
surroundsoundeld.
DirectSound3D Game EXtensions
3.0
GX 3.0 supports EAX gaming sound effects and
DirectSound 3D hardware enhanced functions for
more games on Windows Vista/Win 7 & XP. (DirectX/
DirectSound 3D compatible)
Smart Volume Normalizer
TM
Normalizes the volume of all audio sources into a
constant level and also enhances your 3D sound
listening range and advantages in gaming
FlexBass
TM
Professional Bass Management / Enhancement system
Xear 3D
TM
Virtual Speaker Shifter Virtual 7.1 speaker positioning
Other Effects 10-band Equalier / 27 Environment Effects
ASIO 2.0 Driver Support: Supports 44.1K/48K/88.2K/96K/176.4K/192KHz
@16/24bit with very low latency
