Operation

(Common Interface) menu screen and service

by consulting your dealer.

• Please do not insert or pull out the CI card

when power on. During initialization of the CI

card, please don’t operate the TV.

• Do not insert or pull out the CI card

frequently so as to avoid any damages of the

TV and the CI card.

• If there is no picture and/or sound with the

CI+ CAM module inserted, please contact the

customer support of the service provider.

USB operation

Background information

• This unit supports playback of video files

with 3GP, ASF, AVI, MKV, MPG, DAT, M2TS,

MP4, TS, VOB extension, with video codecs

WMV V9, H263, MPEG-4, MPEGII, XVID and

audio codecs PCM, WAV, MP3, DD(AC3).

The above list of extensions and codecs

is for information only and is not a guarantee

that all files having the above extensions and

codecs sohuld be read by this unit.

• USB file systems supported: NTFS, FAT16,

FAT32. 2.0 USB version is supported, maximum

capacity is 500 GB. Max. load: DC5V, 500 mA.

For correct and satisfactory operation, licensed

USB devices of famous brands should be

used with this unit. Avoid using USB devices of

unknown brands. Playback of some file formats

cannot be supported.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current

consumption exceeding 500 mA is not

recommended without supplementary power

supply. Failure to use supplementary power for

connected USB drives with power consumption

exceeding this value as well as defective

USB drives may cause mechanical or thermal

changes of elements of this unit as well as

failure of internal elements of the USB port.

Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may

cause malfunction of the unit or damage to the

software.

Operations of file playback

• Insert a USB into the USB jack. Select

USB source and press OK button. The screen

will show a USB playback window, in which

you can select Movie, Music, Photo and File

contents to play by pressing LEFT/RIGHT

cursor buttons and OK button.

• Press cursor buttons to select Return

option and press OK button on the RC if you

want to go back to the previous menu.

• In the content menu, press cursor buttons

to select folder, press OK button on the RC

to enter it, then press cursor buttons to select

the file you want to watch or to listen to. When

highlighting the file, the file information will

appear and picture will be previewed (not

available for music files). Press PLAY and

PAUSE buttons on the RC to play the selected

file.

• While playback, press INFO button; the

bottom of the screen will show playback menu

in which you can select an operation by LEFT/

RIGHT cursor buttons on the RC or perform

this operation by pressing OK button on the

RC. Some of the operations are as follows:

Play or pause playback All files

Select previous file All files

Select next file All files

Stop plabyack and return to

previous menu

All files

Select repat playback mode All files

Play music in background

mode when photo or text

file is being browsed (you

should select music file first)


and

Text

Show playlist All files

Show file information All files

Rotate image clockwise Photo

Rotate image anti-clockwise Photo
