viii
H81M-P PLUS specications summary
Specications are subject to change without notice.
Internal I/O
connectors/
buttons/switches
1 x USB 3.0 connector support additional 2 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports
2 x SATA 6.0Gb/s connectors
2 x SATA 3.0Gb/s connectors
1 x 4-pin CPU fan connector (PWM mode)
1 x 4-pin Chassis fan connector (PWM mode)
1 x Front panel audio connector
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
1 x COM header
1 x 14-1 pin TPM header
1 x CLRTC header
1 x Chassis Intrusion header
1 x Speaker connector
1 x System panel connector
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7,
ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3, My Favorites, Quick Note, Last Modied log, F12 PrintScreen, F3
Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Operating System
Support
Windows
®
8.1
Windows
®
8
Windows
®
7
Form factor
uATX form factor: 8.9 in x 6.85 in (22.6 cm x 17.4 cm)
