7-11

ASUS RS100-E8-PI2

9. When nished, click Next.

10. When prompted to restart the computer,

select Yes, I want to restart this

computer now then click Finish to

complete the installation.

8. Click Install in the Windows Security

window.

The Windows Security window may appear more than once and you may have to click Install

several times to continue with the installation.
