Notebook PC E-Manual

Keyboard

The keyboard provides full-sized QWERTY keys with a

comfortable travel depth for typing. It also enables you to use

the function keys, allows quick access to Windows®, and controls

other multimedia functions.

NOTE: The keyboard layout diers by model or territory.

Touchpad

The touchpad allows the use of multi-gestures to navigate

onscreen, providing an intuitive user experience. It also simulates

the functions of a regular mouse.

NOTE: For more details, refer to the Using touchpad gestures

section in this manual.
