xi
(continued on the next page)
X99-PRO/USB 3.1 specifications summary
ASUS Exclusive
Features
Media Streamer
- Pipe music or movies from your PC to a smart TV, your
entertainment goes wherever you go!
- Media Streamer app for portable smartphone/tablet,
supporting iOS 7 and Android™ 4.0 systems
NFC Express 2 support (optional)
- NFC Receiver and 2-port USB 3.0 hub
- NFC one-touch features: Video-to-go, Photo Express, Remote
Desktop, Quick Launch, Windows
®
8 Login, and Bluetooth
®
Gamers and Professionals
Turbo APP
- Perform each application with tailored performance, network
priority, audio conguration, and fan speed for your needs
Turbo LAN
- Experience smooth online gaming with lower pings and less
lag
Crystal Sound 2
- Feel the sound power with different usage scenarios
Steam support
- Compatible with the most fun gaming platform under
Windows
®
system
ASUS EZ DIY
Push Notice
- Monitor your PC status with smart devices in real time
USB BIOS Flashback
- with USB BIOS Flashback Wizard for EZ BIOS download
scheduling
UEFI BIOS EZ Mode
- featuring friendly graphics user interface
- ASUS O.C. Tuner
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Q-Design
- ASUS Q-Code
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector
ASUS Special Features
ASUS 5X Protection:
- ASUS DIGI+ VRM - 8 Phase digital power design
- ASUS Enhanced DRAM Overcurrent Protection - Short circuit
damage prevention
- ASUS ESD Guards - Enhanced ESD protection
- ASUS High-quality 5K-Hour Solid Capacitors - 2.5x long
lifespan with excellent durability
