Asus x99-pro/usb 3.1 [144/150] Chapter 3

3-66

Chapter 3: BIOS setup

Chapter 3

5. Press <Enter> again to launch secure BIOS update. System will enter EZ Flash 2

Updater and continue the BIOS update process.

6. When the BIOS update is done, select OK or press <Enter> to restart your computer.

DO NOT shut down or reset the system while updating the BIOS to prevent system boot

failure.

Ensure to load the BIOS default settings to ensure system compatibility and stability. Select

Load Optimized Defaults item under the Exit BIOS menu. See chapter BIOS setup,

section Exit menu of your User Guide for details.
