ASUS N3150M-E / N3050M-E
1-13
Neverconnecta1394cabletotheUSBconnector.Doingsowilldamagethemotherboard!
TheUSBmodulecableispurchasedseparately.
6. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1/2)
TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA6.0
Gb/ssignalcables.
• TocongurethedefaultSATAtypeinBIOS,clickAdvanced Mode > Advanced tab >
SATA Configuration > SATA Mode.
• Whenusinghot-plugandNCQ,setthe SATA ModeitemintheBIOSto[AHCIMode].
See section 2.5.4 SATA Configuration for details.
5. USB 2.0 connector (10-1 pin USB_E34)
ThisconnectorisforUSB2.0ports.ConnecttheUSBmodulecabletothisconnector,
then install the module to a slot opening at the back of the system chassis. This
USBconnectorcomplieswithUSB2.0specicationthatsupportsupto480Mbps
connection speed.
N3150M-E
N3050M-E
N3150M-E / N3050M-E USB2.0 connector
USB_E34
PIN 1
USB+5V
USB_P3-
USB_P3+
GND
NC
USB+5V
USB_P4-
USB_P4+
GND
GND
RSATA_RXP1
RSATA_RXN1
GND
RSATA_TXN1
RSATA_TXP1
GND
SATA6G_1
GND
RSATA_RXP2
RSATA_RXN2
GND
RSATA_TXN2
RSATA_TXP2
GND
SATA6G_2
N3150M-E
N3150M-E SATA6.0Gb/s connectors
