1-4
Chapter 1: Product introduction
1.2.4 Layout contents
1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithanAM3+socketdesignedforAMD
®
FX™Series/Phenom™II/
Athlon™II/Sempron™100SeriesProcessors.
TheAM3+sockethasadifferentpinoutfromtheAM2+/AM2socket.Ensurethatyouusda
CPUdesignedfortheAM3+socket.TheCPUtsinonlyonecorrectorientation.DONOT
forcetheCPUintothesockettopreventbendingthepinsanddamagingtheCPU!
Connectors/Headers/Slots/LED Page
1. ATXpowerconnectors(24-pinEATXPWR,4-pinATX12V) 1-16
2. CPUandchassisfanconnectors(4-pinCPU_FAN,and3-pinCHA_FAN) 1-15
3. AMDAM3+socket 1-4
4. DDR3DIMMslots 1-8
5. Speakerconnector(4-pinSPEAKER) 1-17
6. Systempanelconnector(10-1pinF_PANEL) 1-18
7. SATA3.0Gb/sconnectors(7-pinSATA3G_1~4) 1-17
8. USB2.0connectors(10-1pinUSB56,USB78) 1-19
9. ClearRTCRAM(2-pinCLRTC) 1-12
10. Frontpanelaudioconnector(10-1pinAAFP) 1-19
M5A78L-M LE/USB3 CPU socket AM3+
