vii
(continued on the next page)
M5A78L-M LE/USB3 specications summary
CPU AMD
®
Socket AM3+ for AMD
®
FX™ / Phenom™ II / Athlon™ II /
Sempron™ 100 series processors
AMD
®
Cool ‘n’ Quiet™ Technology
Supports CPU up to 125W
* Refer to www.asus.com for the AMD
®
CPU support list
Chipset AMD
®
760G(780L) / SB710
Front side bus
Up to 5.2GT/s HyperTransport™ 3.0 interface
Memory
Dual-channel memory architecture
2 x 240-pin DIMM slots support maximum 16GB unbuffered ECC and non-
ECC DDR3 1866 / 1600 / 1333 / 1066MHz memory modules
* AMD
®
FX™ Series CPU on this motherboard supports up to DDR3
1866MHz as its standard memory frequency.
** Due to CPU specication, AMD
®
AM3 CPUs on this motherboard
support up to DDR3 1333MHz.
*** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
Expansion slots 1 x PCIe 2.0 x16 slot
1 x PCIe 2.0 x1 slot
1 x PCI slot
Storage / RAID 4 x Serial ATA 3Gb/s connectors support RAID 0, 1, 10 and JBOD
LAN
Realtek 8111GR Gigabit LAN Controller(s)
Audio Realtek
®
ALC887 8-channel* High Denition Audio CODEC
- Dedicated audio PCB layers: Separate layers for left and right channels
to guard the quality of the sensitive audio signals
- Premium Japanese-made audio capacitors: Provide warm, natural and
immersive sound with exceptional clarity and delity
* Use the chassis with HD audio module in the front panel to support
8-channel audio output.
Package contents
Check your motherboard package for the following items.
Motherboard ASUS M5A78L-M LE/USB3 motherboard
Cables 2 x Serial ATA 3.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
