ix
B150-PRO D3 / B150-PLUS D3 specifications summary
Specifications
B150-
PRO D3
B150-
PLUS D3
Internal
connectors
1 x USB 2.0/1.1 connectors support additional 2 USB
2.0/1.1 ports
1 x USB 3.0/2.0 connectors support additional 2 USB
3.0/2.0 ports
6 x SATA 6.0Gb/s connectors
1 x CPU Fan connector
2 x Chassis Fan connectors
1 x COM header
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x CLRTC
1 x System Panel connector
√ √
BIOS features
128Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0,
WfM2.0, SM BIOS3.0, ACPI 5.0, Multi-language BIOS,
ASUS EZ Flash 3, ASUS CrashFree BIOS 3, F6 Qfan
Control, Quick Note, Last Modied log, F12 PrintScreen,
F3 Shortcut functions and ASUS DRAM SPD (Serial
Presence Detect) memory information
√ √
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE √ √
Support DVD
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
√ √
OS support
Windows
®
10 (64-bit)
Windows
®
8.1 (64-bit)
Windows
®
7 (64-bit/32-bit)*
* Please refer to ASUS website and download “Windows
®
7 installation guide” and “ASUS EZ installer” to install
Windows
®
7.
√ √
Form Factor
ATX Form Factor, 12”x 8.6” (30.5cm x 21.8cm) √ √
Specications are subject to change without notice.
