viii
H110M-D D3 specications summary
ASUS quiet
thermal solution
Quiet Thermal Design
- ASUS Fan Xpert
- Stylish Fanless Design: PCH heatsink
Rear panel I/O
ports
1 x PS/2 keyboard/mouse combo port
2 x USB 3.0/2.0 ports (blue)
2 x USB 2.0/1.1 ports
1 x HDMI port
1 x D-Sub port
1 x LAN (RJ-45) port
1 x LPT port
1 x COM port
3 x Audio jacks support 8-channel audio output*
Internal
connectors
1 x USB 3.0 / 2.0 connector support additional 2 USB 3.0/ 2.0 ports
2 x USB 2.0 / 1.1 connectors support additional 4 USB 2.0/ 1.1 ports
4 x SATA 6.0 Gb/s connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector (AAFP)
1 x S/PDIF out header
1 x TPM header
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
1 x System panel connector
1 x CLRTC jumper
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3,
My Favorites, Quick Note, Last Modied Log, F12 PrintScreen function, and
ASUS DRAM SPD (Serial Presence Detect) memory information
Manageability WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
OS support
Windows
®
10 (64-bit),
Windows
®
8.1 (64-bit),
Windows
®
7 (32-bit / 64-bit)
* Please refer to ASUS ofcial website and download “Windows
®
7 installation
guide” and “ASUS EZ installer” to install Windows
®
7.
Form factor uATX form factor: 8.9 in. x 7.3 in. (22.6 cm x 18.5 cm)
Specications are subject to change without notice.
